• Dual-Band Wi-Fi 6 Gigabit Ceiling AP ZD-WAP622G-S:
• Dual-band four-stream design for the whole unit, offering an access rate of 1.775Gbps, with the 2.4GHz band reaching up to 574Mbps and the 5GHz band up to 1201Mbps.
• 1 Gigabit Ethernet port
• Supports 802.11a/b/g/n/ac Wave 1/Wave 2/ax protocols;
• Supports two-layer roaming.
• Supports easy-to-debug APP management;

Wireless Parameters

Operating Frequency:

802.11ax/ac/n: 5.725 GHz-5.850 GHz (China), 5.15 GHz-5.35 GHz (China); 802.11ax/b/g/n: 2.4 GHz-2.483 GHz (China)

Emission Power:

20 dBm

Space flow number:

2.4GHz：2*2 5GHz：2*2

Transmission Speed:

2.4GHz offers a maximum connection speed of 574Mbps, while 5GHz provides up to 1201Mbps, with the entire unit supporting a connection speed of 1.775Gbps.

Blending Technology:

OFDM：BPSK@6/9Mbps、QPSK@12/18Mbps、16-QAM@24Mbps、64-QAM@48/54Mbps; DSSS： DBPSK@1Mbps、DQPSK@2Mbps、CCK@5.5/11Mbps; MIMO-OFDM(11n)：MCS 0-15; MIMO-OFDM(11ac)： MCS 0-9; MIMO-OFDM(11ax)： MCS 0-11。

Mixing Method:

11b：DSS:CCK@5.5/11Mbps,DQPSK@2Mbps,DBPSK@1Mbps,11a/g：OFDM:64QAM@48/54Mbps,16QAM@24Mbps,QPSK@12/18Mbps,BPSK@6/9Mbps,11n：MIMO-OFDM:BPSK,QPSK,16QAM,64QAM,11ac/ac wave2：MIMO-OFDM:BPSK,QPSK,16QAM,64QAM,256QAM,11ax: MIMO-OFDM: BPSK,QPSK,16QAM,64QAM,256QAM,1024QAM

WLAN Basics:

Maximum number of connected users: 256 | Maximum SSID count supported by single radio: 8

WLAN Security:

Supports RSN, supports TKIP, supports CCMP, supports PSK, supports hidden SSID

Antenna Type:

Built-in, omnidirectional

Network Parameters

Business Port

1 GbE electrical port

General Parameters

Weight:

0.37kg

Operating Temperature:

0 °C - 45 °C

Operating Humidity:

5% - 95% (condensation)

Installation Method:

Ceiling-mounted

Supply Method:

Local Power Supply: Supports 12 V DC, PoE Power Input: IEEE 802.3at

Product Dimensions (Width × Height × Depth):

220 mm × 220 mm × 39 mm

Total Power Consumption:

≤11.35 W
