• 5 Gigabit Ethernet ports
• Switching Capacity: 1Gbps, Packet Forwarding Rate: 0.74Mpps
Exquisite plastic shell design
Plug and Play, no configuration required
• Supports desktop/wall-mounted installation
Functional Features
Port Specifications:
5 Gigabit Ethernet ports
Exchange Method:
Store and Forward
Performance Parameters
Exchange Capacity:
1 Gbps
Packet Forwarding Rate:
0.74 Mpps
MAC Address Capacity:
2 K
Cache:
768 Kbits
General Parameters
Dimensions (W x H x D):
83 mm x 22 mm x 52 mm
Weight:
49 g
Packing List:
Switch *1, Adapter *1, Quick Start Guide *1
Operating Temperature:
0 °C - 40 °C
Working Humidity:
5% - 95% (Non-condensable)
Storage Temperature:
–40 °C~85 °C
Storage Humidity:
5% to 95% (no dew)
Installation Method:
Desktop
Power Supply Method:
5 V DC,0.6 A
Fan:
Fanless
Total Power Consumption:
≤3 W
