• 5 Gigabit Ethernet ports
• Switching Capacity: 10Gbps, Packet Forwarding Rate: 7.44Mpps
Exquisite plastic shell design
Plug and Play, no configuration required
• Supports desktop/wall-mounted installation
Feature specifications
Port Specifications:
5 Gigabit Ethernet ports
Mode of Exchange:
Store and Forward
Performance Parameters
Exchange Capacity:
10 Gbps
Package Forwarding Rate:
7.44 Mpps
MAC Address Capacity:
2 K
Cache:
1 Mbits
General Parameters
Dimensions (Width x Height x Depth):
87 mm × 25 mm × 51 mm
Weight:
59 g
Operating Temperature:
0 °C~40 °C
Working Humidity:
5% - 95% (non-condensable)
Storage Temperature:
-40 °C~85 °C
Storage Humidity:
5% - 95% (non-condensable)
Installation Method:
Desktop with wall mounting option
Power Supply Method:
Local Power Supply: Supports 5 V DC
Fan:
No content provided.
Total Power Consumption:
≤ 3 W
Packing List:
Switch *1, Adapter *1, Quick Start Guide *1
