The testing and maintenance operations for liquid oxygen storage tanks encompass the following aspects:
Appearance Inspection: Conduct regular visual inspections of liquid oxygen tanks, checking for issues such as corrosion, wear, and leakage on the tank surface to ensure the tank's appearance remains intact.
Pressure Testing: Regular pressure tests of the liquid oxygen storage tank are conducted to assess its pressure resistance. The tests should be performed in accordance with relevant standards and regulations, ensuring the tank can withstand the designed working pressure.
Leak Detection: Regularly conduct leak detection on liquid oxygen tanks, including using leak detection equipment to inspect the tanks, to ensure their sealing performance is good and there are no leak issues.
Cleanliness and Coating Protection: Regularly clean and apply protective coatings to liquid oxygen tanks to prevent corrosion and oxidation. Use appropriate cleaning agents during cleaning and avoid substances that react with liquid oxygen. Protective coatings can include anti-corrosion coatings or protective coatings.
Regular Maintenance: Regularly maintain liquid oxygen tanks by inspecting and replacing seals, valves, safety devices, etc., to ensure proper operation and safety.
Safety Training and Operating Procedures: Conduct safety training for personnel using liquid oxygen tanks to ensure they are familiar with the safe operating procedures and precautions, to prevent operational errors and accidents.
Documentation and Record Management: Establish test and maintenance records for liquid oxygen storage tanks, including test results, maintenance logs, and inspection records, for traceability and management purposes.
It is important to note that the testing and maintenance of liquid oxygen tanks should be conducted by trained personnel and in accordance with relevant safety operating procedures and standards. Additionally, a specific testing and maintenance plan should be developed based on the tank's condition and usage requirements, and executed as scheduled.

The leak treatment methods for liquid argon storage tanks mainly include the following steps:
Identify Air Leaks: Discover air leaks in liquid argon storage tanks through methods such as detecting odors, using gas detection equipment, or identifying abnormal pressure in liquid argon storage tanks.
Confirm air leakage location: Use gas detection equipment or foam leak detection agents, etc., to pinpoint the exact location of the air leakage. Check tank interfaces, valves, pipe connections, and other areas to locate the air leakage points.
Cease Air Leaks: Take appropriate measures to stop the air leak source based on the leak location. For instance, for leaks at interfaces, inspect and adjust sealing washers or tighten bolts; for valve leaks, check and replace seals.
Isolate Air Leaks: During the process of dealing with air leaks, it is necessary to isolate the leaky areas to ensure personnel safety. Set up warning signs, restrict access to the area, and take necessary protective measures, such as wearing protective masks, gloves, etc.
Evacuating Liquid Argon: If a leak cannot be repaired immediately or the leak is substantial, consider evacuating the liquid argon. By gradually reducing the pressure inside the storage tank, the liquid argon can be converted into gas, thereby minimizing the risk of air leakage.
Ventilation Treatment: During the air leakage treatment, ensure good ventilation and promptly exhaust the gases produced by the evaporation of liquid argon. Natural ventilation or the use of ventilation equipment can be employed to expel the evaporated gases of liquid argon to the outside.
Safety Assessment and Repairs: After completing the air leakage treatment, conduct a safety assessment to ensure the tank's safety. Based on the assessment results, perform necessary repairs and maintenance to prevent future air leakage.
Note that liquid argon is a low-temperature liquid with a low boiling and freezing point. Caution is required when dealing with air leaks to prevent contact with liquid argon, which can cause coldness. When handling air leaks in liquid argon storage tanks, the operation should be performed by personnel and in accordance with relevant safety operating procedures and standards.

When cleaning low-temperature liquid storage tanks, the following steps should be taken:
Safety Preparations: Prior to cleaning, ensure there are no remaining liquids or gases inside the tank, and that the tank has been fully drained and vented. Wear appropriate personal protective equipment, such as protective suits, gloves, and safety shoes.
Cleaning Agent Selection: Choose a cleaner suitable for low-temperature environments and liquid storage tank materials. Common cleaners include acidic and alkaline solutions, organic solvents, or specialized cleaners. Select the appropriate cleaner based on the tank's material and the nature of the contaminants.
Cleaning Process: Inject the cleaning agent into the tank and use appropriate tools (such as sprayers, brushes, or high-pressure water) to clean the inner walls of the tank. Multiple cleanings can be performed as needed to ensure all contaminants are removed.
Washing and Discharging: After cleaning, rinse with clean water or an appropriate solvent to remove cleaning agents and residues. Ensure the tank is dry and discharge the rinse water into an appropriate treatment system.
Inspection and Verification: After cleaning, inspect the tank to ensure no residual contaminants are left inside. Appropriate detection equipment or methods, such as optical inspection, chemical analysis, or ultrasonic testing, can be used to verify the cleaning effectiveness.
Be mindful that when cleaning low-temperature liquid storage tanks, it's crucial to adhere to relevant safety regulations and operating guidelines. Liquid storage tanks typically possess high flammability and low-temperature characteristics, so operators must strictly follow safety procedures to ensure the safety of personnel and equipment. During the cleaning process, be cautious to prevent leaks of cleaning agents and contaminants, and take appropriate measures for handling and disposal.

Low-temperature liquid storage tanks are equipment designed for storing low-temperature liquids, commonly used for liquid oxygen, liquid nitrogen, liquid argon, and other low-temperature liquids. These liquids are in a gaseous state at room temperature but are cooled to a liquid state at low temperatures for better storage and usage. These tanks are typically made of high-strength materials such as stainless steel or aluminum alloys to withstand low temperatures and high pressures. They often have an insulating layer to minimize evaporation and maintain the low-temperature state. Applications of low-temperature liquid storage tanks include but are not limited to: They are widely used in rocket fuel and propulsion systems, such as liquid oxygen, liquid nitrogen, and liquid hydrogen storage tanks. They store and supply low-temperature liquids as fuel and oxidizers to propel rockets and operate them. Industrial Production: Low-temperature liquid storage tanks are used in industrial production to store and supply low-temperature liquids like liquid oxygen, nitrogen, and argon. These liquids serve as coolants, feedstock for gas separation, and raw materials for chemical reactions in industrial processes. Medical Applications: These tanks are used in medical fields to store and supply liquid oxygen for oxygen therapy, inhalation therapy, and operating rooms. Laboratory Research: In scientific research and laboratories, low-temperature liquid storage tanks provide low-temperature liquids as coolants and cryogenic media. They are used for cooling laboratory equipment, material research, superconductivity, and low-temperature physics. In summary, low-temperature liquid storage tanks are extensively applied in rocketry, industrial production, and laboratory research, storing and supplying low-temperature liquids to meet the demands of various fields.
