During the degreasing process of high vacuum pipelines in low-temperature liquid storage tanks, the following steps can be taken:
Preparation: Ensure the cleanliness and readiness of the defatting equipment and tools. Check the pipeline system's connections and sealing to ensure there are no leaks.
Cleaning Pipelines: Use appropriate cleaning agents and tools to clean the pipelines, removing surface dirt and grease. Methods may include mechanical brushing, high-pressure water jetting, or chemical cleaning.
De-greasing Process: Select an appropriate de-greaser and inject it into the pipeline system. The de-greaser can be an organic solvent or an alkaline solution, the choice depending on the pipeline material and type of dirt. Ensure the de-greaser thoroughly covers the inner pipeline walls and maintains a certain contact time.
Pipe flushing: Drain the degreaser from the pipeline system and flush with clean water to remove any remaining degreaser and dirt. High-pressure water or gas can be used for flushing during the process to ensure the cleanliness of the interior pipeline walls.
Drying Pipes: Evaporate or exhaust moisture inside the pipes using drying equipment or ventilation systems, ensuring the interior pipe walls are dry. Drying can be achieved with hot air or nitrogen.
Inspection and Testing: After degreasing, inspect and test the pipes to ensure cleanliness and sealing. Visual inspections, pressure tests, or other relevant tests can be conducted.
Note that during the degreasing process of high vacuum pipelines for low-temperature liquid storage tanks, it is crucial to adhere to relevant safety operating procedures and guidelines. Ensure that operators possess the necessary safety awareness and operational skills to prevent accidental incidents.

Leakage in liquid argon storage tanks may be caused by the following factors:
Design or Manufacturing Defects: Defects in the design or manufacturing process, such as poor welding, inappropriate material selection, or loose sealing, may lead to leakage issues in the storage tank.
Corrosion and Oxidation: Long-term exposure of liquid argon tanks to low temperatures can lead to corrosion and oxidation. These can damage the tank's surface protective layer, causing leakage issues.
Fatigue and stress cracking: During long-term use, tanks may experience fatigue and stress cracking due to temperature and pressure fluctuations. These cracks can reduce the tank's sealing performance, leading to leaks.
Improper Operation: Failure to follow proper procedures during the storage tank's operation, such as overfilling liquid argon or excessive pressure, can lead to tank damage and leakage.
External Damage: The tank may have sustained damage from external factors such as mechanical impact or objects.

Proper installation of the liquid oxygen safety valve is a crucial step in ensuring the safe operation of liquid oxygen storage tanks. Here are the installation steps for the liquid oxygen safety valve:
Select the appropriate safety valve: Choose a safety valve that meets the design pressure and flow requirements of the liquid oxygen storage tank. Ensure the rated pressure and flow of the safety valve comply with the tank's specifications and adhere to relevant safety standards and regulations.
Valve Installation Location: Select an appropriate location for installing the safety valve. Typically, the safety valve should be mounted on the top or side of the liquid oxygen storage tank to allow for timely pressure release in the event of overpressure.
Preparation for installation interfaces: Prepare the corresponding interfaces based on the connection method of the safety valve. This may include welding interfaces, threaded interfaces, or flange interfaces, etc. Ensure the tightness and firmness of the connections.
Install the safety valve: Mount the safety valve onto the prepared interface. Follow the installation instructions for the safety valve to ensure proper connection and tightening.
Adjustment and Testing: After installation, adjust and test according to the safety valve specifications. Ensure the opening and closing pressures of the safety valve meet the design requirements, and conduct a leak test to verify its sealing integrity.
Identification and Record: Label the safety valve with relevant information such as rated pressure, flow rate, and installation date. Additionally, record the installation details and test results for future reference and maintenance.
When installing the liquid oxygen safety valve, it is imperative to adhere to relevant safety regulations and operating guidelines. If you lack the necessary experience and knowledge, it is advisable to seek assistance and guidance from a professional to ensure the correct installation and reliable operation of the safety valve.

When storing liquid nitrogen in low-temperature storage tanks, be mindful of the following points:
Protective Gear: When handling low-temperature storage tanks, it is mandatory to wear appropriate protective gear, including gloves, protective suits, and non-slip shoes. This equipment can safeguard the skin from the low temperatures of liquid nitrogen and other hazards.
Avoid direct contact: Liquid nitrogen is extremely cold and can cause chilling. Therefore, it is essential to avoid direct contact with liquid nitrogen, particularly with the skin. Use tools or implements for handling, to prevent hands from coming into direct contact with liquid nitrogen.
Ventilation Requirements: In the operational area of low-temperature storage tanks, adequate ventilation must be ensured to expel gases produced by the evaporation of liquid nitrogen. Maintain air circulation to avoid excessive oxygen concentration, and reduce the risk of fire and explosion.
Prevent Leaks: Regularly inspect the low-temperature storage tanks for leaks and equip with leak detectors and alarm systems. In case of a leak, take immediate action to control and repair it. Avoid the hazards of liquid nitrogen leaks to personnel and the environment.
Fire Prevention Measures: Liquid nitrogen has a low boiling and freezing point, which can easily cause fires. Measures such as setting up fire barriers around low-temperature storage tanks and using fire-retardant coatings are taken to prevent fires from occurring and spreading.
Electrostatic Protection: Electrostatic buildup in low-temperature storage tanks may cause sparks, increasing the risk of fire. Measures should be
