Shandong Zhongjie Special Equipment's main products include: fuel (gas) boilers, organic heat carrier boilers, biomass boilers, waste heat recovery boilers, and other boiler products; vacuum insulation cryogenic pressure vessels such as LNG storage tanks, oxygen/nitrogen/argon storage tanks, and CO2 storage tanks; pressure vessel products such as denitrification engineering equipment, heat storage and energy storage equipment, and complete chemical equipment; central air conditioning and HVAC equipment such as ground (water) source heat pumps, air source units, water-cooled screw units, and air-cooled modular units. Planned products include large-scale energy centers, LNG transport vehicles, LNG tank containers, and other green energy equipment.
以下是一些常见的二氧化碳储罐管理守则： 安全管理：建立完善的安全管理制度，包括安全操作规程、应急预案和事故处理程序等。确保操作人员具备必要的安全知识和技能，并定期进行安全培训和演练。 储罐检查和维护：定期检查储罐的外观、阀门、连接件等，确保其完好无损。定期进行泄漏检测和压力测试，确保储罐的安全性能符合要求。 液位监测和控制：定期监测储罐内的液位，确保储罐内的二氧化碳充足。根据需要进行充填或放空操作，维持适当的液位。 废气处理：处理二氧化碳储罐产生的废气，避免对环境造成污染。采取适当的废气处理措施，如收集和处理废气。 防火防爆措施：采取防火防爆措施，确保储罐周围的环境安全。远离火源、高温区域和易燃物质，定期检查和维护防火设施。 标识和警示：储罐应明确标识，包括储存的气体类型、压力等信息。周围应设置警示标志，提醒人员注意储罐的存在和相关安全注意事项。 储存记录：记录储罐的使用情况，包括充填日期、充填量、检查记录等。定期进行储罐的检测和维护，并保留相关记录。 定期审查和改进：定期审查储罐管理制度和操作流程，及时发现问题并进行改进。根据实际情况进行风险评估和管理，提高管理水平和安全性能。 需要注意的是，具体的管理守则可能会因不同的储罐类型和应用而有所不同。在管理二氧化碳储罐时，应根据相关的规范和标准进行操作，并咨询人士以确保安全和有效性。

1.相关知识 of Low-Temperature Carbon Dioxide Storage Tanks The structure of low-temperature carbon dioxide storage tanks typically consists of a double-walled cylindrical design, with the inner tube made of 6MnDR alloy steel and the outer tube of Q245R or Q345R pressure vessel steel plate. The piping is made of austenitic stainless steel, and the insulation space is filled with high-vacuum sintered sand or wrapped with multiple layers for thermal insulation. The storage tanks are equipped with valves for operation, which are arranged for ease of use. Pressure gauges and level indicators are also installed to monitor the internal pressure and liquid level of the low-temperature carbon dioxide storage tanks. 2.Main Features of Low-Temperature Carbon Dioxide Storage Tanks (1) The storage tanks are equipped with liquid filling connections for tanker trucks, enabling the supply of liquid to vaporizers, tanker trucks, and pumps. (2) Both the inner and outer cylinders of the storage tanks are equipped with safety devices to ensure safe operation for users. (3) The insulation material of the low-temperature carbon dioxide storage tanks is specially treated to provide a longer vacuum life. Additionally, the tanks are equipped with vacuum gauges for measuring the insulation space vacuum when needed. 3.Transportation of Low-Temperature Carbon Dioxide Storage Tanks (1) During road transportation, the storage tanks should be securely fastened to the vehicle, travel at moderate speeds, and avoid collisions with other objects. (2) After the storage tanks arrive, the unloading crew should work with the equipment supervisor to develop a scientific and reasonable unloading plan. 4.Installation of Low-Temperature Carbon Dioxide Storage Tanks (1) Upon arrival at the installation site, the storage tanks can be positioned once the installation conditions are met. During the installation process, avoid impacts and strikes, and pay special attention to the explosion-proof equipment on the outer cylinder and the vacuum valve, which should not be touched. (2) Perform an airtightness test on the inner cylinder system of the storage tanks using nitrogen to the working pressure. After confirming that valves, pipes, flanges, etc., are leak-free, the installation is complete. (3) The installation dimensions of the low-temperature carbon dioxide storage tanks are specified in the supply materials. When considering liquid filling and emptying with tanker trucks, account for the vehicle's travel path.

Pressure Vessel Standards: Liquid carbon dioxide storage tanks are generally considered pressure vessels, and their design, manufacture, and use should comply with the relevant pressure vessel standards. In China, common pressure vessel standards include GB150 "Steel Pressure Vessels" and GB18435 "Storage Tanks." Safety Standards: The use of liquid carbon dioxide storage tanks should comply with relevant safety standards and regulations. For instance, in China, the safe use of liquid carbon dioxide storage tanks should adhere to standards such as GB50028 "Design Code for Petroleum and Chemical Enterprises" and GB50016 "Building Design Fire Prevention Code." Inspection and Testing Standards: The inspection and testing of liquid carbon dioxide storage tanks should comply with the relevant standards and regulations. For example, the regular inspection of liquid carbon dioxide storage tanks can refer to standards like GB/T 19638 "Code for Periodic Inspection of Pressure Vessels." Environmental Protection Standards: The use of liquid carbon dioxide storage tanks should comply with relevant environmental protection standards and regulations. For instance, in China, the exhaust emissions from liquid carbon dioxide storage tanks should meet standards such as "Air Pollutant Emission Standards."

清洁低温液体储罐的过程需要谨慎操作，以确保安全性和有效性。以下是一般的清洁步骤： 安全准备：在清洁液体储罐之前，确保储罐内的液体已经完全排空，并且储罐的压力已经释放。确保所有相关的安全设备和阀门处于关闭状态。 防护措施：低温液体储罐通常存储着冷的液体，如液氮或液氧。在进行清洁操作时，必须佩戴适当的个人防护装备，如绝缘手套、、防护服等，以防止冷或其他伤害。 清洁剂选择：选择适合清洁低温液体储罐的清洁剂。清洁剂应具备良好的腐蚀性能和低温适应性。可以咨询清洁剂供应商或储罐制造商以获取建议。 清洁过程：将清洁剂注入储罐中，使用适当的工具（如喷洒器、刷子等）进行清洁。根据储罐的尺寸和污染程度，可以选择手动清洁或使用清洗设备。 冲洗和排放：清洁完成后，使用清水或其他适当的冲洗剂进行冲洗，以确保清洁剂和污物。冲洗完成后，将废水和废液排放到合适的处理系统中，遵循环境保护的相关规定。 检查和验证：清洁完成后，进行储罐的检查和验证，确保储罐内部干净、无残留物，并符合相关的安全和卫生要求。 需要注意的是，清洁低温液体储罐的具体步骤和要求可能会因不同的储罐设计和使用场景而有所差异。在进行清洁操作时，应遵循相关的安全操作规程和标准，确保操作的安全性和有效性。好咨询工程师或储罐制造商以获取具体的清洁指导。
Zhongjie Special Equipment upholds the grand vision of "realizing employees' dreams, creating value for customers, and striving for the prosperity and strength of our motherland," and is dedicated to the development of the green energy equipment industry. We offer products and services with high cost-performance to contribute to society!
