Rectifier Bridge Assemblyo Core components, typically consisting of four diodes (single-phase) or six diodes (three-phase), form a full-wave rectifier bridge circuit. o Diodes are responsible for conducting the positive and negative half-cycles of AC input current to the DC output terminal.

　　Input Voltage:AC Input Voltage Specifications (e.g., Single Phase 110/220V ±15% or Three Phase 380V ±15%).

　　· Input Frequency:Typically 50/60 Hz.

　　· Rated Output Voltage:Desired DC output voltage (e.g., 48V, 24V).

　　· Rated Output Current:Rated current for continuous module operation.

　　· Output Power/Capacity:Output Voltage * Output Current.

　　· Efficiency:Output Power/Input Power x 100%. Modern high-efficiency rectifier modules can achieve efficiencies of 96%-99%.

　　· Power Factor:Enter the ratio of active power to apparent power. PWM rectifiers can achieve a PF greater than 0.99.

　　· Voltage Regulation Rate:Stability of output voltage under voltage fluctuations or load changes.

　　· Load Adjustment Rate:The range of output voltage from no-load to full-load.

　　· Waveshape Voltage/Coefficient:The magnitude of the AC component superimposed on the DC output.

　　· Operating Temperature Range:Operating temperature for the module to function normally.
