Flat Auto Polishing Machine, Automatic Board Sanding Machine, Planar Polishing Machine, Stainless Steel Polishing Machine LC-C313
Total Power: 15 kW.
Sandpaper Motor: 11KW - 4 Pole
Sandpaper belt speed: 7.83 m/s.
Sandpaper Size: 1600*1300mm.
Transmission Motor: RV90 1:50 with 3KW.
Conveyor speed: 13 m/min.
Processing Range: 5-1280mm x 300-6000mm x 0.8-50mm (width x length x thickness).
Suitable for surface texturing, sanding, polishing, and embossing on various types of boards. The machine is versatile for both dry and wet operations, equipped with a feeding stand. Water grinding reduces sand belt wear and prevents board warping due to heat. Strict dynamic balancing eliminates the occurrence of vibration marks on both sides of the board. The four-column lifting system completely improves the issue of an uneven worktable. Strict requirements for sheet metal and painting make the machine's design sleek and dynamic.
