DPZ-500 Electrohydraulic Rod Valve  Double Rod Valve  Coal Storage Manual Plug Valve

Equipment Introduction:

Single Layer Rod ValveDouble-strand bar gate is a new type of gate developed to meet the needs of industries such as construction materials, mining, and metallurgy for the transportation control and feeding of medium and small-sized solid and blocky materials. It is suitable for material control of ≤50mm size. The bar gate comes in single-layer, double-layer, manual, pneumatic, and electro-hydraulic versions, including manual single-layer bar gate and double-layer electro-hydraulic bar gate.

Application Scope: Primarily used for conveying control and feeding processes of small to medium-sized solid and blocky materials in industries such as construction materials, mining, and metallurgy.

Features:

The rod valve features a simple structure and ease of operation, without any sticking, overcoming the drawback of flat gate valves that require excessive force to open and close, or even struggle to close due to large particle sizes of the material. Thanks to the single rod operation, it offers convenient and flexible operation. The overall structure is welded steel section, ensuring good rigidity, no deformation, and a long service life, with no need for maintenance. It is an ideal equipment for controlling small and medium-sized crystalline and blocky materials.
