NanGongThe Collapsible LED Advertising Trailer is mainly composed of four major parts: the towing system, the large-screen system, the power supply system, and the operating system. It features the capability to fold the large screen.
Application ScenarioCorporate promotion, on-site displays, sports events, concerts, and music shows, etc.

NanGong Advertising TrailerTechnical Specifications: (Subject to the confirmed plan by both parties)

1. Load capacity of2.5tons. Body length of6.3Rice, width1.8Metric tons.

2. The frame is welded using square rectangular tubes, fully enclosed with cold-rolled sheets on the surface.

3. Utilize4Thread500-8Solid tires, single wheel load1.2TRated Speed15KM/HInside.

4. Swivel joint type steering.

5. This vehicle is equipped with a parking brake (handbrake, applies to both wheels).

6. The vehicle is towable and can be steered manually.

7. Each side of the vehicle's body has an amplifier box, equipped with laser-cut speaker vent holes.

8. Screen Net Size: Length6.08Rice, high3.2Meters.

Display Stand Dimensions: Designed according to the net size of the display screen, the stand is designed to be collapsible for easy transportation.
