NanGong12T Electric Trailer Chassis Electric Flatbed Truck
Detailed Technical Requirements:
I. Case Body Section
The main manufacturing process of the cabinet uses welding assembly, with the bottom frame joined and covered with panels on the surface, fixed at the front, back, and top, and fitted with wing doors on both sides.
2. Front and rear end corner sheet metal bending with small circular arcs for assembly and welding, with inspection and operation windows opened according to the drawings.
3. The side wing doors are assisted by gas springs.
4. The housing chassis and vehicle body design are detachable, secured by bolts.
5. Note: Additional costs for installing secret compartments, pipes, or wiring are not included in this price.
Section II: Chassis Component
1. This vehicle is designed for dual-purpose towing and self-propulsion.Electric TrailerSimple and practical operation, stable performance.
2. The body manufacturing process uses sheet metal welding, with the vehicle's carrying capacity at 3 tons. The frame body width is 1.65 meters, length 3 meters, and height 0.5 meters. Thickened type
Steel welding is resistant to deformation.
3. The undercarriage suspension utilizes leaf spring shock absorption, equipped with two sets of 2.5-ton axles, front axle steering and rear axle driving.
4. Equipped with four 600-9 pneumatic tires for movement, each tire supports a load of 1.2 tons. Self-propelled speed ranges from 0 to 5 km/h, while牵引 speed is up to 25 km/h.
5. The self-propelled traction conversion utilizes an electromagnetic clutch, which closes when the unit is self-propelled and opens during traction towing.
6. Power source is a 48V 100A lithium iron phosphate battery with a charger, powered motor is 48V 3KW, steering with electric push and hydraulic push rod.
7. Button Remote Control; features include start/stop, forward/reverse, left/right turn; remote control range up to 100 meters.
8. Equipped with battery boxes, toolboxes, and electrical control boxes on both sides. The vehicle's interior features a walking sound and light horn.
9. Yellow paint finish.

The 12T electric trailer chassis flatbed truck is researched, developed, and manufactured by Nangong Vehicle. It features electric remote operation and can also be manually towed, offering dual functionalities.
Application ScenarioElectric flatbed trucks are suitable for container transportation at airports, ports, and within factories.
