Main Functions and Design Scheme of Lab Bench Control System:
1. Utilizing a closed-loop control system, information about the system's operation is collected via sensors and other acquisition systems. The collected data is then input into a computer via a data acquisition card, where it is displayed and calculated according to control requirements. Subsequently, control signals are output, processed by the data acquisition card into signals recognizable by the actuator, and finally, system control is achieved through the actuator's operation.
2. Utilizing a centralized computer control system with PLC hardware and a WINDOWS software platform. During the signal acquisition process, we collect both digital and analog signals. Therefore, we first need to convert the analog signal data into digital signals that the PLC can process. After PLC processing, some of the output signals must be converted back into analog signals to control the experimental bench. This requires both A/D and D/A conversions. Hence, an integrated data acquisition card with both functions is needed to accomplish these conversions.
