Mine coal storageDEZElectro-hydraulic actuated sector gate 鄂式Loading and Unloading Dust Valve

Operation of a Breech Gate Generally, it's used for loading trucks in material or gray warehouses.

Bib Gate[2]Please note the medium flow direction marked on the gate body during installation. When connecting the two flanges, seal washers must be added, followed by evenly tightening the bolts.

Next, during operation, please identify the direction of the butterfly valve switch and correctly wire the actuator. It's crucial to regularly lubricate all transmission parts during operation to extend the lifespan of the gate valve.

Improper operation can increase the wear on the palate valve.

Pit gate applications

Bib GateSuitable for bulk materials such as various ores, coal, coke, slag, chemical products, etc., with a specific gravity of ≤2.5t/m³, widely used in the unloading of materials at the bottom of storage bins in industries such as building materials, metallurgy, chemicals, and glass.

The globe valve is composed of components such as the main body, sector gate, shaft, gears, seals, and actuator. Made of carbon steel welded into shape, it features a unique structure, flexible and reliable operation, with no jamming. Different transmission devices can be used to meet various operational requirements. The electric globe valve uses an electric actuator with overload protection to prevent motor burnout and allows for remote or programmable control. The reciprocating travel can be adjusted to lock in position. The electro-hydraulic globe valve employs an electro-hydraulic actuator with full hydraulic transmission, allowing for variable speed control of both thrust and pull forces. The pneumatic globe valve utilizes a pneumatic actuator, which can be remotely controlled or locally operated through component assembly.
