Material Loading Gate Swing Type Jaw Gate DEZ-700 Electro-Hydraulic Push Rod Gape Valve
Electro-hydraulic three-way分流阀 also known as an electro-hydraulic three-way分流solenoid valve, electro-hydraulic three-way分流pilot, or wye valve. Available in manual, electric, and pneumatic types, the electro-hydraulic three-way分流valve comes in two configurations: straight three-way and lateral three-way.
Electro-hydraulic three-way分流阀Utilizes electro-hydraulic push rods as the power source. Featuring automatic overload protection, when the operation is obstructed, the pressure in the oil circuit increases to the set limit, and the overflow valve quickly and accurately overflows, implementing overload protection. The motor operates within the rated value without burning out. When the push rod reaches the set travel terminal, an automatic locking mechanism is designed in the oil circuit module of the electro-hydraulic push rod, stopping the motor. The piston rod locks in this position, maintaining pressure. Among them...The DSF-A(B) type electro-hydraulic three-way分流阀 is suitable for material reversing/diversion processes.
Electro-hydraulic three-way manifold distributor structural features:
1. Well-designed, with complete specifications and models, our product series offers ease of selection, versatility, and strong comprehensive compatibility. Operation is simple, and maintenance is straightforward.
2. Compact overall structure, lightweight, energy-efficient, low noise, and easy to install.
3. If the power source is an electro-hydraulic push rod or electro-hydraulic rotating actuator, it features rapid and flexible operation, load-starting capability, and automatic overload protection. Both thrust and pull forces can be infinitely adjusted, offering a wide driving force range, and can... Adjust reciprocating stroke.
4. Broad Application Range. The series of batching dividers and their matching designs are widely applicable for the storage and transportation of bulk materials in various industries.
5. Automated control for remote operation, display of opening signals, and remote or centralized control capabilities.
