Product Performance:
Environmentally friendly, free of heavy metals.
2. High reuse times: Standard model has a 3000 cycles at 80% DOD and 2000 cycles at 100% DOD; Model C (High Reuse) can reach up to 5000 cycles at 80% DOD and 3500 cycles at 100% DOD.
3. Low self-discharge rate, ≤2% per month, no memory effect
4. Lightweight with twice to thrice the energy density of traditional lead-acid batteries.
5. Easy installation, battery pack can be mounted in a 19-inch standard rack or wall-mounted
6. In interface design, all harnesses are selected with plug-and-socket connections for easy installation.
7. Compact size, with a volume-to-energy ratio approximately twice that of a standard lead-acid battery.
Wide temperature range: -20~+60°C, excellent high-temperature resistance.
9. Flexible configuration, supports parallel expansion
10. Fast-charging performance is excellent, with 1C fast charging, 95% of the rated capacity is fully charged in one hour.
11. FTTH as an alternative to FTTB (FTTx), simple to use
Product List:
| Model | Nominal Voltage (V) | Rated Capacity/Ah | Size (mm) | Voltage Limit for Charging (V) | Breakdown Voltage (V) | Weight/kg | |||
| Width (mm) | Depth/H (mm) | Height: H (mm) | Total Depth | ||||||
| LFeLi-4810 | 51.2 | 10 | 442 | 330 | 44 | 351.5 | 57.6 | 43.2 | 9.5 |
| LFeLi-4820 | 51.2 | 20 | 442 | 330 | 88 | 358 | 57.6 | 43.2 | 14 |
| LFeLi-4830 | 51.2 | 30 | 436 | 400 | 132.5 | 434 | 57.6 | 43.2 | 20 |
| LFeLi-4840 | 51.2 | 40 | 436 | 400 | 132.5 | 434 | 57.6 | 43.2 | 25 |
| LFeLi-4850 | 51.2 | 50 | 436 | 400 | 132.5 | 434 | 57.6 | 43.2 | 28 |
| LFeLi-4850C | 48 | 50 | 443 | 441.5 | 132 | 472 | 54.0 | 40.5 | 32 |
| LFeLi-4850D | 51.2 | 50 | 436 | 350 | 132.5 | 385 | 57.6 | 43.2 | 26 |
| LFeLi-4860 | 51.2 | 60 | 436 | 400 | 132.5 | 434 | 57.6 | 43.2 | 33 |
| LFeLi-4875C | 48 | 75 | 440 | 401.5 | 177.5 | 453.5 | 54.0 | 40.5 | 42 |
| LFeLi-4880 | 51.2 | 80 | 436 | 420 | 220 | 453 | 57.6 | 43.2 | 39 |
| LFeLi-48100 | 51.2 | 100 | 436 | 420 | 220 | 453 | 57.6 | 43.2 | 49 |
| LFeLi-48100C | 48 | 100 | 442 | 395 | 222 | 450 | 54.0 | 40.5 | 62 |
| LFeLi-48100D | 51.2 | 100 | 436 | 350 | 221.5 | 385 | 57.6 | 43.2 | 48 |
