IP Column

Standard with 1 x 10/100M RJ45 network interface, supporting both Local Area Network (LAN) and Wide Area Network (WAN) transmission.

2. Features 1 line input for easy connection with other signals

3. Standard with 3-way customizable dry contact input (0V signal) interface, allowing users to easily select preset voice options

4. Supports remote server management and upgrades for easy user maintenance

5. (Optional) Built-in 128M audio storage, capable of erasing and copying 6 songs via TF card, selecting preset music signals with a switch, and triggering the playback of preset voice programs.

6. The internal power amplifier features overheat, overvoltage, and short-circuit protection functions.

7. Volume output is adjustable

8. Equipped with 2 5-inch speakers, a 4-inch horn, aluminum housing, aluminum mesh grille, and a white appearance.

8. High-fidelity Amplified Speakers, with built-in D-Class digital amplifier, high efficiency

(Optional) Pre-recorded Voice:

Hello, please sort the trash and put it in the bins (female voice)

2. Ornamental lawn, please do not trample (female voice)

3. Vehicle lane, pedestrians prohibited

4. Upon entering the construction site, please wear a hard hat and be mindful of safety.

5. Caution area, please leave immediately.

6. You have entered a monitored area. Your actions are being recorded in real time. Please be mindful of your conduct.

Technical Specifications:

Input Power: AC 220V

2. Network Interface: 1 set of RJ45

3. Transmission Rate: 100Mbps/10Mbps

4. Supported Protocols: TCP/IP, UDP, IGMP (Multicast)

5. Sampling Rate: 8K to 48K

6. Frequency Response: 80Hz - 16KHz

7. Harmonic Distortion: THD ≤ 0.1%

8. Signal-to-Noise Ratio: ≥85dB

9. Circuit Protection: Over-temperature Protection Circuit

10. Rated Power: 60W/8Ω

11. Protection Level: IP66

12. Transmission Cables: Round Plug Power Cord

13. Dimensions: 620x170X150mm

14. Operating Temperature: -15°C to 55°C

15. Working Humidity: 20% - 80% Relative Humidity

16. Weight: Net Weight 3.1 kg
