Job Characteristics

1. The handheld box features a 320*240 high-resolution color screen and a full Chinese operating interface, easy to learn and use.

2. Features both blowing and suction operation modes.

3. Supports multiple screw bins in suction feeding mode.

4. Supports extended applications such as screw locking, potting, welding, inspection, handling, assembly, etc.

5. Supports dual work platforms and dual boot modes.

6. Support for retry or skip mode when a failure occurs.

7. Features regional array copy, platform copy, batch editing, and single-step execution functions.

8. Action parameters edited, download them to the controller via serial port, allowing for standalone operation off-line. Additionally, you can save the action parameters to a handheld box for easy access.

9. Stores hundreds of processing files, each supporting up to 1,000 screw positions, ready to retrieve and use.

Product Advantages

Supports the import function for computer graphics CAD drawing files, capable of importing DXF files.

2. A rich set of sports commands and auxiliary instructions.

3. User-friendly file guidance and editing features, including batch modification, array copy, graphic translation, graphic scaling, automatic rounding corners, and various advanced editing functions. Equipped with a commonly used graphic library for easy customer access.

4. Graphical display function, offering a highly intuitive depiction of the graphic shapes within the processing files; real-time dynamic display of the machining path.

5. Quick and convenient help system, accessible by pressing Shift+F1 on any interface.

6. Processing methods support recycling processing, single processing, automatic processing, and step-by-step processing, etc.
