KSTPanels include floor panels, roof panels, truss panels, gutter panels, and wall panels. Refer to the catalog number.15CJ63/15CG26。
Application Scope: Seismic fortification intensity less than or equal to in non-earthquake areas8Industrial and civil construction in various regions.
Suitable for normal environments, with an average annual humidity of less than or equal to75%Structures. For environments with special requirements, use after taking appropriate measures.
Floor panels are suitable for floors in general industrial and residential buildings that only bear vertical loads (such as mezzanine floors).
Roof panels, grid panels, and gutter panels are suitable for roof pitches less than or equal to1/10General industrial and civil construction.
The wall panels are suitable for external wall panels in general industrial buildings. When used in residential buildings, the panels should meet the relevant regulatory requirements for waterproofing, thermal insulation, sound insulation, fire resistance, etc.
Project | Floor panel | Roofing panels | ||
Width:m） | 1.2 | 1.2 | 1.5 | 2.4 |
Length:m） | 3.0-6.0 | 9.0-12 | 3.0-9.0 | 6.0-7.5 |
Project | Web Slat | Gutter panel | Wall Panel | |
Width:m） | 2.7-4.2 | 0.9 | 1.0 | 1.5 |
Length:m） | 2.7-4.2 | 4.5-12 | 4.5-9.0 | 4.5-9.0 |
FCTechnical Performance Specifications Two
Carbonization Coefficient | Softening Coefficient | Freezing Resistance100Next freeze-thaw cycle | |
Quality Loss%） | Strength loss%） | ||
≥0.80 | ≥0.82 | ≤1.2 | ≤23 |
KSTThe load-bearing period of the structural components of the board's design50Year, roof panels, wall panels, and gutter panels. The wall panels are calculated with simply supported supports on both sides along the board length: considering the steel frame and the secondary rib frame.FCThe synergistic benefits of the integrated steel mesh, without the need for whole material and performance adjustments of the section steel:
Polymer cement waterproof coating, alkali-resistant glass fiber mesh.35ThickFCInternally equipped with钢丝网、EPSSheet.
KSTBoard features main frame, sub frame, sub rib, upright rod, double-layered space wire mesh.EPSSheetFCComposed of alkali-resistant glass fiber mesh and polymer cement waterproofing coatings, etc.
FCTechnical Performance Specifications
Dry Densitykg/m³） | Compressive StrengthMPa） | Flexural strengthMPa） | Tensile Split StrengthMPa） | Tensile Strength of Vertical Plate SurfaceMPa） | Elastic ModulusMPa） |
400-450 | ≥2.0 | ≥0.23 | ≥0.40 | ≥0.194 | ≥14900 |
500-550 | ≥2.2 | ≥0.24 | ≥0.47 | ≥0.197 | ≥16300 |
Dry Densitykg/m³） | Poisson's ratio | Thermal Conductivity CoefficientW/(M.K)） | Heat Storage Coefficientw/(㎡.k）） | Steam Vapour Transparencyg/（㎡.s.pa）） | |
400-450 | ≤036 | ≤0.089 | ≥1.645 | ≤1.46×10 | |
500-550 | ≤0.33 | ≤0.091 | ≥1.695 | ≤1.25×10 | |
Body stability calculation.
Manufacturing, transportation, storage, installation, maintenance:
KSTThe boards are joined by welding or bolt connections; when welding is used, the cold-weather quality grade is:
Grade 3, weld length not less than50mm、
Internal mesh wire is circular.5With round3Welded wire mesh, featuring circular...5For reinforcement bars subjected to loads, the depth into the support shall be not less than50mmPlease provide the Chinese content to be translated.3For distributed reinforcing bars, the depth into the support shall not be less than30mmAnd there should be a transverse rib within the bracket.
To ensure the integrity of the core material, the upper layer should be cast before the lower layer begins to set.
The core material is poured higher than the steel frame during the casting of the roof surface of the roof panels and the outer surface of the wall panels.20mmThe thickness of the reinforcement protective layer ≥20mmNo random holes are allowed on the steel frame light board; when the hole size isD＞200mmAt this time, a separate design should be made, and provisions should be made in advance during setup. Special circumstances requiring on-site drilling should be completed with the cooperation of the manufacturer.
KstThe board frame should be treated for rust removal, with the rust removal grade beingst2.c06-1Two coats of iron red alkyd anti-rust paintc04-2Two coats of alkyd magnetic paint in various colors, film thickness not specified.120μmThe steel frame and core material contact surface is not painted.
When the core material reaches the designed strength70%When ready for transportation and hoisting, the vehicle should be equipped with wooden blocks, light panels should be stacked flat and securely tied down, and the overhang length of the light panels should not exceed600mm。
kstBoards should be handled using machinery for second transportation and lifting, with individual pieces being lifted separately.
The steel frame lightweight panels should be stacked on a level and firm ground. The height of each pile should not exceed...10Blocks, spacer wood height should be uniform, aligned top and bottom.
kstWhen installing the board, the length of the board resting on the bracket must not be less than60mmAfter positioning, the main ribs of the roof and floor should be securely welded to the supports, with the weld length not being less than60mmWeld seam height4mm, and shall ensure3Spot welding. Reinforce the overall connection points of roof and floor panels as required for seismic resistance.
