PET Silicone Tape/Green High Temperature Adhesive Tape Parameters Description
| Custom Processing & Tailoring: | Is | Base Material: | Base Material |
| Thickness (mm): | (mm) 0.06/0.08/0.1mm | Width (mm): | 0-1080mm, as per customer |
| Color: | Clear/Green/Blue/ | Long-term temperature resistance: | 150℃ |
| Short-term thermal resistance: | 200℃ | Adhesive System: | Silicone |
| Model: | GJ-05 | Specification: | 1080mm |
| Packaging: | Custom Made | Thermal resistance: | 200℃ for 30 minutes with no residual glue |
| Tensile elongation at break: | (%) 120 | Length: | (m) 33～66 |
| Tensile strength: | (kg/25mm) 124/155 | Adhesion: | (n/25mm) 6.2 |
| Production Volume: | 10000 |
PET Silicone Tape/Green High Temperature Adhesive Tape Detailed Description
Product Description:
High-temperature resistant polyester tape is made from polyester film base coated with imported high-temperature resistant silicone pressure-sensitive adhesive. The tape features high-temperature resistance, electrical insulation, chemical resistance, high adhesion, softness, and easy repositioning without leaving residue. It is suitable for electroplating, high-temperature baking paint, and powder coating industries. Common thickness specifications are currently:0.05mm, 0.06mm, 0.08mm, 0.09mm; custom thickness products available.
Product Specifications:
Color Transparent/Green / Blue /
Base material Polyester Film
Thickness(mm) 0.05/0.06/0.08/0.1mmm
Adhesive strength(n/25mm) 6.2
Tensile Strength(kg/25mm) 124/155
Tensile elongation at break(%) 120
Thermal resistance(℃) 200℃ for 30 minutes, no residual glue
Length(m) 33～66
Width(mm) 0-1080mm, custom-made to customer's specification
Product Features:
This product boasts high shape retention, excellent resistance to chemicals, corrosion, and moisture, as well as the ability to withstand cutting and abrasion. It also features flame retardant and insulating properties.
Product Applications:
Application: Specifically designed for use in the immersion process of circuit boards, it covers the gold fingers to prevent the electroplating solution from seeping in and contaminating, thereby protecting the circuit board. It features straight edges, is easy to tear off, and leaves no residue. Also serves as an insulating material for winding transformers, motors, coils, capacitors, and inverter power supplies in the electronics industry.
