The ultrasonic cleaner consists of a generator and an ultrasonic transducer. The generator emits high-frequency oscillation signals, which are converted into high-frequency mechanical oscillations by the transducer and propagated through the medium. This generates thousands of tiny bubbles, which form and grow in the negative pressure zone of the ultrasonic longitudinal propagation and rapidly collapse in the positive zone, continuously producing momentary high pressure. This冲击the surface of the object, causing dirt on the surface and in the crevices to quickly fall off, thereby achieving the cleaning purpose. Compared to other cleaning methods, the ultrasonic cleaner demonstrates significant advantages, especially in specialized or corporate groups, gradually replacing traditional immersion, brushing, and pressure washing processes. Its cleaning speed is several to even dozens of times faster than traditional methods, and the cleanliness reaches the highest standard. In many high-quality and high-efficiency applications, it highlights the effects that other treatment methods cannot achieve or replace.

Ultrasonic Transducer

Detailed Description:

The overall assembly of the ultrasonic transducer's amplitude transformer is called a vibration element. The vibration element is very particular about the overall compatibility of the transducer and the amplitude transformer. We can supply the housing and lead wires, ensuring the maximum stability of product quality and striving to minimize the labor required by our customers! The vibration elements we use are highly reliable.

Key Features:

1. Low calorific value 2. Good thermal stability 3. Strong consistency between frequency and static capacitance 4. Low resonance impedance

5. Long service life 6. Widely applicable in various ultrasonic cleaning equipment

Product Description: Acid and alkali resistant, aesthetically pleasing and durable, adjustable power, equipped with an automatic solvent heating device, temperature control range 30°C-110°C.
