Clean various heat exchangers, condensers, industrial pipelines, boilers, and steam power plant equipment condensers. Greentech Chemicals offers guaranteed cooperation.

Jining Green Chemical Technology Co., Ltd. (abbreviated to Jining Green Cleaning Co.) was established in 2010 and specializes in the cleaning of various industrial heat exchange equipment. The company boasts comprehensive business philosophy and the capability to research and develop industrial cleaning technologies. We undertake cleaning services for industrial, private enterprise, and corporate chemical equipment, power station equipment, power plant condensers, boilers, and boiler air preheaters; as well as air conditioning cleaning, heat exchange equipment cleaning, and cleaning of machinery and chemical equipment. We also handle the cleaning and descaling of refrigeration and heating equipment.

Jining Grean Cleaning Company stocks dozens of cleaning machines ranging from 10mpa to 250mpa, and over a dozen chemical cleaning pump stations. Our main services are to power plants, chemical factories, oil refineries, food processing plants, corporate entities, and heating equipment, among others. The company also provides long-term industrial heat exchanger cleaning and design services to industry clients.

Our company has newly acquired domestic cleaning machines and imported cleaning equipment. We have hired experienced technical specialists in the cleaning industry, which has standardized and regulated the cleaning process for heat exchange equipment.

Chemical Cleaning Scale Removal Process

Recirculating Closed Circuit Cleaning

Recirculation cleaning utilizes two original parallel ash piping lines to form a loop, creating a circulating system with the cleaning pump station. It involves adding a certain concentration of acidic solution, which circulates and cleans within the ash water pipes. Additionally, as the acid cleaning reaches a certain level, the acidic solution is continuously replenished. For short-distance single ash water pipelines, if conditions permit, a temporary pipeline can be laid to create a recirculating loop for cleaning. This process must be carried out while the system is shut down, and it is complex and costly.

Open Path Cleaning

No two grey pipes can form a loop during cleaning; only single grey pipe open circuit cleaning is allowed. The method involves connecting one end of the grey pipe to the cleaning device, continuously preparing a specific concentration of cleaning solution in the dosing tank, and injecting it into the grey pipe continuously or intermittently. This process requires adding cleaning equipment while the system is offline, which increases costs.

Continuous operation cleaning

The process involves continuously injecting a certain amount of acidic solution while the ash pipeline is operating normally without interruption. Simultaneously, a certain quantity of ash pipeline operation cleaning inhibitor and pipeline descaling agent is added for open-loop cleaning. The primary function of the cleaning aid is to promote the reaction between the acidic solution and the ash scale at a certain concentration and flow rate, while also increasing its solubility in water, reducing the occurrence of air blockages, and ensuring the quality of ash pipeline cleaning.

Operation method: Prior to cleaning, first estimate the required acid quantity based on the total scale in the pipeline. Then, calculate the acid addition rate and the flow rate for the injection of corrosion inhibitors and pipeline cleaning strippers based on the flow rate of sludge water and acidity. During cleaning, take samples at the sampling point at the front end of the sludge pipe every 30 minutes to test the acidity and strictly control it by adjusting the acid flow rate. In the later stage of cleaning, take samples at the end of the sludge pipe every 15 minutes to test the pH value. When the pH value reaches a certain level and remains unchanged for 30 minutes, the cleaning process can be considered complete.


2. High-pressure water jet cleaning equipment
High-pressure water jet cleaning offers advantages such as high efficiency, low cost, non-damaging to workpieces, environmental friendliness, ease of operation, and safety.
High-pressure water technology boasts the following advantages.

(1) High-quality Cleaning: During the cleaning of pipelines and the inner holes of heat exchangers with high-pressure water jet, all scale and obstructions within the pipes can be thoroughly removed, revealing the metal surface. The high-pressure water jet, with its immense energy and ultra-sonic speed, is capable of completely destroying stubborn scale and obstructions without causing any damage to the metal.

Due to the pressure of high-pressure water being less than the compressive strength grade of metal, high-pressure cleaning will not damage the base material being cleaned.

(2) Fast Cleaning Speed: Due to the combined crushing actions of water jetting, wedging, shearing, and abrasion, scale can be quickly broken and removed, which is several to tens of times faster than traditional chemical methods, sandblasting, simple mechanical, and manual cleaning methods.

Components cleaned with high-pressure water jetting do not require secondary cleaning; however, after chemical cleaning, the surface chemicals must be rinsed off with clear water.

(3) No Environmental Pollution: Since high-pressure water jet cleaning uses pure water as the medium, it does not generate large amounts of dust like sandblasting, shot blasting, or simple mechanical cleaning, which can pollute the atmosphere and harm health. It also does not produce a significant amount of waste liquid like some chemical cleaning methods, which can contaminate rivers, soil, and water quality. The water jet cleaning with pure water is odorless, tasteless, and non-toxic. After atomization, it can also reduce the dust concentration in the work area, lowering atmospheric dust from 80mg/m³ using other methods to below the national safety standards, thus causing no pollution.

Pipe Scale

(1) Categorized by chemical composition, they include carbonate scale, sulfate scale, silicate scale, and mixed scale, etc. The main components of carbonate scale are calcium carbonate and magnesium carbonate; the main components of sulfate scale and silicate scale are calcium sulfate and silicate compounds, respectively.

(2) Categorized by physical properties, there are two types: scale that is firmly adhered to the pot shell and pipe walls, and sediment that is loosely textured and easily detached.
Lime scale primarily forms due to the salts like calcium and magnesium in the boiler feed water that precipitate and adhere to the metal surface upon heating. Lime scale has a very low thermal conductivity, approximately 2 to 5 times that of ordinary steel. When lime scale accumulates on the boiler's heat transfer surface, it significantly worsens heat transfer efficiency and affects the boiler's performance; it can also easily damage metal materials due to localized overheating, potentially leading to pipe explosion accidents; it accelerates galvanic corrosion, causing pipeline lime scale corrosion, and speeds up the deterioration of the heat transfer surface. Once lime scale forms, it should be promptly removed using either mechanical or chemical methods.
