Clean various heat exchangers, condensers, industrial pipelines, boilers, and steam power plant economizers. Glan Chemical Co., Ltd. offers guaranteed cooperation.

Jining Greentech Chemical Technology Co., Ltd. (简称 Jining Greentech Cleaning Co.) was established in 2010 and is a professional company specializing in the cleaning of various industrial heat exchange equipment. The company boasts comprehensive business philosophy and the capability to develop industrial equipment cleaning technologies, handling cleaning services for industrial, private enterprise, and corporate chemical equipment, power station equipment, power plant condensers, boilers, and boiler air preheaters; as well as air conditioning cleaning, heat exchange equipment cleaning, and mechanical and chemical equipment cleaning. We also undertake cleaning services for refrigeration and heating equipment, including descaling.

Jining Greentech Cleaning Co. has dozens of cleaning machines ranging from 10mpa to 250mpa, and over a dozen chemical cleaning pump stations. Our primary services include power plants, chemical factories, oil mills, food factories, corporate entities, and heating equipment. Additionally, we offer long-term industrial heat exchanger cleaning and solution design services to industry clients.

Our company has newly acquired domestic cleaning machines and imported cleaning equipment. We have hired experienced technical specialists in the cleaning industry to achieve standardized and standardized cleaning of heat exchange equipment.

Chemical Cleaning Scale Removal Process

Recirculating Closed Loop Cleaning

Recirculating cleaning utilizes two original parallel ash pipelines to form a loop, creating a circulation system with the cleaning pump station. A certain concentration of acidic solution is added, which circulates through the ash water pipeline for cleaning. Additionally, as the acid washing reaches a certain level, the solution is continuously replenished with more acid. For short-distance single ash water pipelines, if conditions permit, a temporary pipeline can be laid to form a recirculation loop for cleaning. This process must be carried out while the system is offline, and it is complex and costly.

Break-open Cleaning

No two ash pipes can form a loop during cleaning; only a single ash pipe should be used for open-loop cleaning. The method involves connecting one end of the ash pipe to the cleaning unit, continuously preparing a certain concentration of cleaning solution in the mixing tank, and then continuously or intermittently injecting it into the ash pipe. This process requires additional cleaning equipment during shutdown, resulting in higher costs.

Continuous operation cleaning

This process involves continuously injecting a certain amount of acidic solution while operating under normal ash conveying conditions without halting the conveyance. Simultaneously, a specific amount of ash conveying pipe cleaning inhibitor and pipeline descaling agent are injected. The cleaning is conducted by opening the circuit. The main function of the cleaning aids is to promote the reaction between the acidic solution and ash scale at a certain concentration and flow rate, while also enhancing its solubility in water and reducing the occurrence of airlock, ensuring the quality of ash pipe cleaning.

The procedure is as follows: Prior to cleaning, first estimate the required acid amount based on the total scale in the pipeline. Then, calculate the acid addition rate and the flow rate of the sludge pipeline cleaning inhibitor and pipeline cleaning descaler based on the gray water flow and acidity. During cleaning, take a sample at the front end of the gray pipe every 30 minutes to test the acidity and strictly control it by adjusting the acid flow rate. In the later stage of cleaning, take a sample at the end of the gray pipe every 15 minutes to test the pH value. When the pH value reaches a certain level and remains unchanged for 30 minutes, the cleaning can be considered complete.


2. High-pressure water jet cleaning equipment
High-pressure water jet cleaning offers advantages such as high efficiency, low cost, non-damaging to workpieces, non-polluting the environment, ease of operation, and safety.
Advantages of high-pressure water technology include:

(1) Excellent Cleaning Quality: The high-pressure water jet cleaning of pipeline and heat exchanger bores can completely remove scale and blockages inside, revealing the metal substrate. With immense energy and moving at supersonic speeds, the high-pressure water jet is fully capable of destroying hard scale and blockages without causing any damage to the metal.

Due to the pressure of high-pressure water being less than the compressive strength grade of metal, high-pressure cleaning will not damage the substrate being cleaned.

(2) Rapid Cleaning Speed - Due to the combined abrasive actions of water jetting, wedge splitting, shearing, and grinding, scale can be quickly shattered and removed, up to several to tens of times faster than traditional chemical methods, sandblasting and shot peening, simple mechanical, and manual cleaning methods.

Components cleaned with high-pressure water jet do not require secondary cleaning; however, after chemical cleaning, the surface chemical needs to be rinsed off with clean water.

(3) No Environmental Pollution: Since high-pressure water jet cleaning uses pure water as the medium, it does not generate a large amount of dust like sandblasting, shot blasting, or simple mechanical cleaning, which can pollute the atmosphere and harm health. It also does not produce a large volume of waste liquid like some chemical cleaning methods, which can pollute rivers, soil, and water quality. The water jet cleaning with pure water as the medium is odorless, tasteless, and non-toxic. After atomization, it can also reduce the dust concentration in the work area, lowering atmospheric dust from 80mg/m³ with other methods to below the national safety standards, thus causing no pollution.

Pipe Scale

(1) Classified by chemical composition, it can be divided into carbonate scale, sulfate scale, silicate scale, and mixed scale, etc. The main components of carbonate scale are calcium carbonate and magnesium carbonate; the main components of sulfate scale and silicate scale are calcium sulfate and silicate compounds, respectively.

(2) Classified by physical properties, there are two types: scale that is firmly adhered to the pot shell and pipe walls, and sediment that is loosely textured and easy to detach.
Lime scale primarily forms due to the salts of calcium and magnesium in the boiler feed water, which precipitate and adhere to the metal surface upon heating. Lime scale has a very low thermal conductivity, about 2 to 5 times that of ordinary steel. When lime scale accumulates on the boiler's heating surface, it significantly worsens heat transfer efficiency and affects the boiler's performance; it can also easily cause metal materials to burn due to local overheating, potentially leading to pipe explosion accidents; it accelerates galvanic corrosion, causing pipeline lime scale corrosion, and speeds up the deterioration of the heating surface. Once lime scale forms, it should be promptly removed using mechanical or chemical methods.

Heat exchanger and refrigeration equipment cleaning, choose Green Chemical Industry for reliability.
