Clean various heat exchangers, condensers, industrial pipelines, boilers, and steam power plant condensers. Glan Chemical Co. offers guaranteed cooperation.

Jining Green Chemical Technology Co., Ltd. (abbreviated to Jining Green Cleaning Co.) was established in 2010 and is a professional company specializing in the cleaning of various industrial heat exchange equipment. The company has comprehensive business philosophy and the capability to develop industrial cleaning technologies, undertaking cleaning services for industrial, private enterprise, and corporate chemical equipment, power plant equipment, condensers, boilers, and air preheaters. We also provide air conditioning cleaning, heat exchange equipment cleaning, and accept cleaning projects for machinery and chemical equipment. Additionally, we handle cleaning and descaling of refrigeration and heating equipment.

Jining Greentech Cleaning Co. has dozens of cleaning machines of various models ranging from 10mpa to 250mpa, as well as more than a dozen chemical cleaning pump stations. Our main services include power plants, chemical factories, oil mills, food factories, enterprises and institutions, heating equipment, etc. The company also offers long-term industrial heat exchanger cleaning and solution design services to industry clients.

Our company has newly acquired domestic cleaning machines and imported cleaning equipment. We have hired experienced technical specialists in the cleaning industry to standardize and normalize the cleaning of heat exchange equipment.

Chemical Cleaning Scale Removal Process

Recirculating Closed Circuit Cleaning

Recirculating cleaning utilizes two existing parallel ash piping lines to form a loop, creating a recirculation system with the cleaning pump station. A certain concentration of acidic solution is added, which circulates through the ash water pipes for cleaning. As the acid washing decreases to a certain level, the acidic solution is continuously replenished. For short-distance single ash water pipes, if conditions permit, a temporary pipeline can be laid to form a recirculation loop for cleaning. This process must be carried out while the system is shut down, and it is complex and costly.

Open Channel Cleaning

No two ash pipes should form a loop during cleaning; only a single ash pipe should be used for open-circuit cleaning. The method involves connecting one end of the ash pipe to the cleaning unit, continuously preparing a specific concentration of cleaning solution in the dosing tank, and then injecting it into the ash pipe continuously or intermittently. This process requires additional cleaning equipment during shutdown, resulting in higher costs.

Continuous cleaning without shutdown

The process involves continuously injecting a certain amount of acidic solution while the ash pipe is running normally without interruption, simultaneously adding a specific quantity of ash-pipe running cleaning inhibitor and pipeline descaling agent. This is an open-circuit cleaning method. The primary function of the cleaning aids is to promote the reaction between the acidic solution and the ash scale at a certain concentration and flow rate, while also increasing its solubility in water and reducing the formation of air blockages, ensuring the quality of ash pipe cleaning.

The procedure is as follows: Before cleaning, first estimate the required acid amount based on the total scale in the pipeline. Then, calculate the acid addition rate and the flow rate of the sludge pipeline cleaning inhibitor and pipeline cleaner stripper based on the flow rate of the gray water and acidity. During cleaning, take a sample at the sampling point at the front end of the gray pipe every 30 minutes to test the acidity, and strictly control the acidity by adjusting the flow rate of acid addition. In the later stage of cleaning, take a sample at the end of the gray pipe every 15 minutes to test the pH value. When the pH value reaches a certain level and remains unchanged for 30 minutes, the cleaning can be considered complete.


2. High-pressure water jet cleaning equipment
High-pressure water jet cleaning offers advantages such as high efficiency, low cost, non-damaging to workpieces, environmental friendliness, ease of operation, and safety.
The high-pressure water technology offers the following advantages.

(1) Excellent Cleaning Quality: During high-pressure water jet cleaning of pipes and internal surfaces of heat exchangers, all scale and obstructions within the pipes are thoroughly removed, revealing the metal surface. The high-pressure water jet, with its immense energy and supersonic speed, can completely destroy tough scale and obstructions without causing any damage to the metal.

Since the pressure of high-pressure water is less than the compressive strength grade of metal, high-pressure cleaning will not damage the base material being cleaned.

(2) Fast Cleaning Speed: Due to the combined crushing effects of water jet washing, wedging, shearing, and grinding, scale can be quickly broken and removed, which is several to ten times faster than traditional chemical methods, sandblasting, ball-blasting methods, simple mechanical, and manual cleaning techniques.

Components cleaned with high-pressure water jetting do not require secondary cleaning; however, after chemical cleaning, the surface chemicals must be rinsed off with clean water.

(3) No Environmental Pollution: As high-pressure water jet cleaning uses pure water as the medium, it does not produce a large amount of dust like sandblasting, shot blasting, or simple mechanical cleaning, which can pollute the atmosphere and harm health. It also does not generate a large volume of waste liquid like some chemical cleaning methods, which can contaminate rivers, soil, and water quality. The water jet cleaning using pure water is odorless, tasteless, and non-toxic. After atomization, it can also reduce the dust concentration in the work area, lowering atmospheric dust levels from 80mg/m³ using other methods to below the national safety standards, thus causing no pollution.

3. Scale in piping

(1) Categorized by chemical composition, it includes carbonate scale, sulfate scale, silicate scale, and mixed scale, among others. The primary components of carbonate scale are calcium carbonate and magnesium carbonate; for sulfate scale and silicate scale, the main components are calcium sulfate and silicate compounds, respectively.

(2) Classified by physical properties, there are two types: a solid scale that firmly adheres to the pot shell and pipe walls, and a loose sediment that is easy to detach.
Lime scale primarily forms due to the salts of calcium and magnesium in the boiler feed water that precipitate and adhere to the metal surface upon heating. Lime scale has a very low thermal conductivity, around 2 to 5 times less than that of ordinary steel. When lime scale accumulates on the boiler's heating surface, it severely degrades heat transfer efficiency and affects the boiler's performance; it can also easily damage metal materials due to localized overheating, potentially leading to pipe explosion accidents; it accelerates galvanic corrosion, causing pipeline lime scale corrosion and speeding up the deterioration of the heating surface. Once lime scale forms, it should be promptly removed using mechanical or chemical methods.

Heat exchanger and refrigeration equipment cleaning, choose Grean Chemical for reliability.
