Clean various heat exchangers, condensers, industrial pipelines, boilers, and steam power plant condensers. GlanChem partnership is guaranteed.

Jining Green Chemical Technology Co., Ltd. (abbreviated to Jining Green Cleaning Co.) was established in 2010 and is a professional company specializing in the cleaning of various industrial heat exchange equipment. The company boasts comprehensive business philosophy and the capability to research and develop industrial cleaning technologies. We undertake cleaning services for industrial, private enterprises, corporate chemical equipment, power station equipment, power plant condensers, boilers, and boiler air preheaters; as well as air conditioning cleaning, heat exchange equipment cleaning, and the cleaning of machinery and chemical equipment. We also handle cleaning and descaling of refrigeration and heating equipment.

Jining Greentech Cleaning Co. has dozens of cleaning machines in various models ranging from 10MPa to 250MPa, and over a dozen chemical cleaning pump stations. We primarily serve enterprises such as power plants, chemical factories, oil mills, food factories, public institutions, heating equipment, and more. The company also provides long-term industrial heat exchanger cleaning and design services for industry clients.

Our company has newly acquired domestic cleaning machines and imported cleaning equipment. We have hired experienced technical specialists in the cleaning industry to achieve standardization and regularization in heat exchanger cleaning.

Chemical Cleaning Scale Removal Process

Recirculating Closed Circuit Cleaning

Recirculation cleaning utilizes two original parallel ash piping lines to form a loop, creating a circulating system with the cleaning pump station. It involves adding a solution of a specific acidity concentration, which circulates through the ash water pipes for cleaning. As the acid cleaning process reaches a certain level, the solution is continuously replenished. For short-distance single ash water pipelines, if conditions permit, a temporary pipeline can be laid to form a recirculation loop for cleaning. This process must be carried out while the system is shut down, and it is complex and costly.

Open road cleaning

No two ash pipes should form a loop during cleaning; only a single ash pipe should be used for open circuit cleaning. The method involves connecting one end of the ash pipe to the cleaning unit, continuously preparing a certain concentration of cleaning solution in the blending tank, and then continuously or intermittently injecting it into the ash pipe. This process requires the addition of cleaning equipment during shutdown, which increases costs.

Continuous cleaning without shutdown

This process involves continuously injecting a certain amount of acidic fluid while operating the ash delivery pipeline to run cleaning inhibitors and pipeline descaling agents, performing an open circuit cleaning. The primary function of the cleaning aids is to promote the reaction between the acidic fluid and the ash scale within a specific concentration and flow rate, simultaneously increasing its solubility in water and reducing the occurrence of airlock, ensuring the quality of ash pipeline cleaning.

The procedure is as follows: Before cleaning, first estimate the required acid amount based on the total scale in the pipeline. Then, calculate the acid addition rate and the flow rate of the descaling agent and pipeline cleaner by considering the sludge flow rate and acidity. During cleaning, take a sample at the sampling point at the front of the sludge pipe every 30 minutes to test the acidity and strictly control it by adjusting the acid flow rate. In the later stages of cleaning, take a sample at the end of the sludge pipe every 15 minutes to test the pH value. When the pH value reaches a certain level and remains unchanged for 30 minutes, the cleaning can be deemed complete.

2. High-pressure water jet cleaning machinery
High-pressure water jet cleaning offers advantages such as high efficiency, low cost, non-damaging to workpieces, environmental friendliness, ease of operation, and safety.
Advantages of high-pressure water technology include:

(1) Excellent Cleaning Quality: The high-pressure water jet cleaning of pipes and the internal cavities of heat exchangers can thoroughly remove scale and blockages from inside the pipes, revealing the metal surface. The high-pressure water jet, with its immense energy and supersonic speed, is capable of completely destroying hard scale and blockages without causing any damage to the metal.

Since the pressure of high-pressure water is less than the compressive strength grade of metal, high-pressure cleaning will not damage the base material being cleaned.

(2) Fast Cleaning Speed: Due to the combined effects of water jet scouring, splitting, shearing, and grinding, scale can be quickly broken and removed, making the cleaning process several to ten times faster than traditional chemical methods, sandblasting, simple mechanical, and manual methods.

Additionally, parts cleaned with high-pressure water jetting do not require secondary cleaning; however, after chemical cleaning, the surface chemical must be rinsed off with clear water.

(3) No Environmental Pollution: Since high-pressure water jet cleaning uses pure water as the medium, it does not produce a large amount of dust like sandblasting, shot blasting, or simple mechanical cleaning, which can pollute the atmosphere and harm health. Nor does it generate a large volume of waste liquid like some chemical cleaning methods, which can contaminate rivers, soil, and water quality. The water jet cleaning with pure water as the medium is odorless, tasteless, and non-toxic. After atomization, it can also reduce the dust concentration in the work area, lowering atmospheric dust from 80mg/m³ with other methods to below the national safety standards, thus causing no pollution.

3. Pipe Scale

(1) Categorized by chemical composition, they include carbonate scale, sulfate scale, silicate scale, and mixed scale. The primary components of carbonate scale are calcium carbonate and magnesium carbonate; for sulfate and silicate scales, the main components are calcium sulfate and silicate compounds, respectively.

(2) Categorized by physical properties, there are two types: a hard scale that firmly adheres to the pot shell and pipe walls, and a loose sediment that is easy to detach.
Lime scale primarily forms due to the salts like calcium and magnesium in the boiler feed water precipitating and adhering to the metal surface upon heating. Lime scale has a very low thermal conductivity, approximately 2 to 5 times that of ordinary steel. When lime scale accumulates on the boiler's heating surface, it severely degrades heat transfer efficiency and affects the boiler's performance; it can easily cause metal materials to burn due to localized overheating, even leading to pipe explosion accidents; it also accelerates galvanic corrosion, causing pipeline lime scale corrosion and speeding up the damage to the heating surface. Once lime scale forms, it should be promptly removed using mechanical or chemical methods.

Heat Exchanger and Refrigeration Equipment Cleaning - Choose GreenChem for Confidence
