Clean various heat exchangers, condensers, industrial pipelines, boilers, and power station equipment condensers - GlanChem Cooperation Ensures Reliability

Jining Greentech Chemical Technology Co., Ltd. (abbreviated to Jining Greentech Cleaning Co.) was established in 2010 and specializes in the cleaning of various industrial heat exchange equipment. The company possesses comprehensive business philosophy and the capability to develop industrial equipment cleaning technologies, undertaking cleaning services for industrial, private enterprises, corporate chemical equipment, power plant equipment, condensers, boilers, and economizers. We also provide air conditioning and heat exchange equipment cleaning, as well as cleaning for mechanical and chemical equipment. We also handle the cleaning of refrigeration and heating equipment for scale removal.

Jining Greentech Cleaning Co. offers a wide range of cleaning machines from 10mpa to 250mpa, with dozens in stock and over a dozen chemical cleaning pump stations. Our main services include power plants, chemical factories, oil refineries, food processing plants, corporate entities, and heating equipment. Additionally, we provide long-term industrial heat exchanger cleaning and design solutions for industry clients.

Our company has newly acquired domestic cleaning machines and imported cleaning equipment. We have hired experienced technical specialists in the cleaning industry to achieve standardized and standardized cleaning of heat exchange equipment.

Chemical cleaning scale removal process:

Recirculating Closed-loop Cleaning

Recirculating cleaning utilizes two existing parallel ash removal pipelines to form a loop, creating a recirculation system with the cleaning pump station. A certain concentration of acidic solution is added, which circulates through the ash water pipeline for cleaning. As the acid washing reaches a certain level, the acidic solution is continuously replenished. For short-distance single ash water pipelines, if conditions permit, a temporary pipeline can be laid to form a recirculation loop for cleaning. This process must be carried out while the system is offline, and it is complex and costly.

Pilot cleaning

No two gray pipes can form a loop during cleaning; only a single gray pipe can be used for open circuit cleaning. The method involves connecting one end of the gray pipe to the cleaning unit, continuously preparing a specific concentration of cleaning solution in the solution tank, and then continuously or intermittently injecting it into the gray pipe. This process requires the addition of cleaning equipment during shutdown, which increases costs.

Continuous cleaning without shutdown

The process involves continuously injecting a certain amount of acidic solution while simultaneously adding a specific quantity of ash conveying pipe cleaning inhibitor and pipeline descaling agent, conducting an open circuit cleaning. The main function of the cleaning aids is to promote the reaction between the acidic solution and ash scale at a certain concentration and flow rate, while also enhancing its solubility in water, reducing the occurrence of air blockage, and ensuring the quality of ash pipe cleaning.

The procedure is as follows: Prior to cleaning, estimate the required acid amount based on the total scale in the pipeline. Then, calculate the acid addition rate and the flow rate of the sludge pipeline for the addition of cleaning inhibitors and pipeline descaler based on the sludge flow rate and acidity. During cleaning, take samples at the front sampling point of the sludge pipeline every 30 minutes to test the acidity and strictly control it by adjusting the acid flow rate. In the later stage of cleaning, take samples at the end of the sludge pipeline every 15 minutes to test the pH value. When the pH value reaches a certain level and remains unchanged for 30 minutes, the cleaning can be deemed complete.


2. High-pressure water jet cleaning equipment
High-pressure water jet cleaning offers high efficiency, low costs, non-damaging to workpieces, environmental friendliness, ease of operation, and safety.
High-pressure water technology boasts the following advantages.

(1) Excellent Cleaning Quality - The high-pressure water jet cleaning for pipes and heat exchanger bores can thoroughly remove all scaling and blockages inside, revealing the metal substrate. The high-pressure water jet, with its immense energy and supersonic movement, is fully capable of destroying hard scaling and blockages, yet it has no damaging effect on the metal.

Since the pressure of high-pressure water is less than the compressive strength grade of metal, high-pressure cleaning will not damage the base material being cleaned.

(2) Fast Cleaning Speed: Due to the combined crushing effects of water jet flushing, wedging, shearing, and grinding, scale can be quickly broken and removed, which is several to ten times faster than traditional chemical methods, sandblasting, ball shooting, simple mechanical, and manual cleaning methods.

Parts cleaned with high-pressure water jetting require no additional cleaning process; however, those chemically cleaned must be rinsed with clear water to remove the surface chemicals.

(3) No Environmental Pollution: Since high-pressure water jet cleaning uses pure water as the medium, it does not produce a large amount of dust like sandblasting, shot blasting, or simple mechanical cleaning, which can pollute the atmosphere and harm health. Nor does it generate a large volume of waste liquid like some chemical cleaning methods, which can contaminate rivers, soil, and water quality. The water jet cleaning using pure water is odorless, tasteless, and non-toxic. After atomizing the jet, it can also reduce the dust concentration in the work area, lowering atmospheric dust levels from 80mg/m³ using other methods to below the national safety standards, thus causing no pollution.

Pipe Scale

(1) Classified by chemical composition, they can be categorized into carbonate scale, sulfate scale, silicate scale, and mixed scale, etc. The main components of carbonate scale are calcium carbonate and magnesium carbonate; the main components of sulfate scale and silicate scale are calcium sulfate and silicate compounds, respectively.

(2) Classified by physical properties, there are two types: water scale that is firmly adhered to the pot shell and pipe walls, and sludge that is loosely textured and easily detached.
Lime scale primarily forms due to the salts of calcium and magnesium in the boiler feed water, which precipitate and adhere to the metal surface upon heating. Lime scale has a very low thermal conductivity, approximately 2 to 5 times that of ordinary steel. When lime scale accumulates on the boiler's heating surface, it significantly worsens heat transfer efficiency and affects the boiler's performance; it can easily cause metal materials to burn due to localized overheating, even leading to pipe explosion accidents; it also accelerates galvanic corrosion, causing pipeline lime scale corrosion and speeding up the damage to the heating surface. Once lime scale forms, it should be promptly removed using mechanical or chemical methods.

Heat Exchanger & Refrigeration Equipment Cleaning - Choose Green Chemical for Confidence
