Clean various heat exchangers, condensers, industrial pipelines, boilers, and power plant equipment condensers. GlanChem partnership offers assurance.

Jining Greentech Chemical Technology Co., Ltd. (简称 Jining Greentech Cleaning Co.) was established in 2010 and is a professional company specializing in the cleaning of various industrial heat exchange equipment. The company has comprehensive business philosophy and the capability to develop industrial equipment cleaning technologies. We undertake cleaning services for industrial, private enterprise, and corporate chemical equipment, power plant equipment, condensers at power plants, boilers, and boiler air preheaters; as well as air conditioning and heat exchange equipment cleaning. We also handle cleaning and descaling of refrigeration and heating equipment.

Jining Grean Cleaning Co. boasts dozens of cleaning machines ranging from 10mpa to 250mpa, and over a dozen chemical cleaning pump stations. Our main services are provided to power plants, chemical factories, oil mills, food factories, corporate entities, heating equipment, and more. The company also offers long-term industrial heat exchanger cleaning and design solutions to clients in the industry.

Our company has newly acquired domestic cleaning machines and imported cleaning equipment. We have hired experienced technical experts in the cleaning industry, enabling the cleaning of heat exchange equipment to be standardized and normalized.

Chemical Cleaning Scale Removal Process

Recirculating closed-loop cleaning

Recirculating cleaning utilizes two existing parallel deslagging pipelines to form a loop with the cleaning pump station, introducing a solution of a certain acidity concentration, which circulates and cleans within the sludge water pipes. As the acid cleaning decreases to a certain level, the solution is continuously replenished. For short-distance single sludge water pipelines, if conditions permit, a temporary pipeline can be laid to create a recirculating loop for cleaning. This process must be carried out while the system is shut down and is complex, with higher costs.

Breakbulk Cleaning

During cleaning, two grey pipes cannot form a loop; only single-pipe open circuit cleaning is allowed. The method involves connecting one end of the grey pipe to the cleaning unit, continuously preparing a specific concentration of cleaning solution in the dosing tank, and then injecting it into the grey pipe continuously or intermittently. This process requires additional cleaning equipment during shutdown, leading to higher costs.

Continuous operation cleaning

The process involves continuously injecting a certain amount of acidic solution while simultaneously introducing a specific quantity of ash conveying pipeline cleaning inhibitor and pipeline descaling agent. This is an open-circuit cleaning method. The primary function of the cleaning aids is to promote the reaction between the acidic solution and the ash scale at a certain concentration and flow rate, while also increasing its solubility in water and reducing the formation of air blockages, ensuring the quality of ash pipe cleaning.

The procedure is as follows: Before cleaning, first estimate the required acid amount based on the total scale in the pipeline. Then, calculate the acid addition rate and the flow rate of the descaling agent and pipeline cleaning agent based on the sludge water flow rate and acidity. During cleaning, take a sample at the front end of the sludge pipe every 30 minutes to test the acidity and strictly control it by adjusting the acid flow rate. In the later stage of cleaning, take a sample at the end of the sludge pipe every 15 minutes to test the pH value. When the pH value reaches a certain level and remains unchanged for 30 minutes, the cleaning can be considered complete.


2. High-pressure water jet cleaning equipment
High-pressure water jet cleaning offers advantages such as high efficiency, low cost, non-damaging to workpieces, environmental friendliness, ease of operation, and safety.
High-pressure water technology boasts the following advantages.

(1) Excellent Cleaning Quality: During the high-pressure water jet cleaning of pipes and the internal holes of heat exchangers, all scale and blockages inside the pipes are thoroughly removed, revealing the metal substrate. The high-pressure water jet, with its immense energy and supersonic speed, is fully capable of destroying hard scale and blockages, yet it exerts no destructive force on the metal.

Due to the pressure of high-pressure water being less than the compressive strength grade of metal, high-pressure cleaning will not damage the base material being cleaned.

(2) Fast Cleaning Speed: Due to the combined actions of jet washing, wedge splitting, shearing, and grinding, scale can be quickly broken and removed, making the cleaning process several to ten times faster than traditional chemical methods, sandblasting, simple mechanical, and manual methods.

Components cleaned with high-pressure water jetting do not require secondary cleaning; however, after chemical cleaning, the surface chemicals must be rinsed off with clear water.

(3) Non-Environmental Pollution: As high-pressure water jet cleaning uses pure water as the medium, it does not generate large amounts of dust like sandblasting or simple mechanical cleaning, which can pollute the atmosphere and harm health. It also does not produce a large volume of waste liquid like some chemical cleaning methods, which can contaminate rivers, soil, and water quality. The water jet cleaning using pure water is odorless, tasteless, and non-toxic. After atomizing the spray, it can also reduce the dust concentration in the work area, lowering atmospheric dust from 80mg/m³ with other methods to below the national safety standards. Therefore, it does not cause any pollution.

Pipe Scale

(1) Classified by chemical composition, they include carbonate scale, sulfate scale, silicate scale, and mixed scale. The main components of carbonate scale are calcium carbonate and magnesium carbonate; the main components of sulfate scale and silicate scale are calcium sulfate and silicate compounds, respectively.

(2) Categorically classified by physical properties, there are two types: water scale that is firmly adhered to the pot body and pipe walls, and sediment that is loosely textured and easy to dislodge.
Scale primarily forms due to the salts of calcium, magnesium, and other substances in the boiler feed water that precipitate and adhere to the metal surface upon heating. The thermal conductivity of scale is very low, about 2 to 5 times that of ordinary steel. The formation of scale on the boiler's heat-absorbing surface greatly worsens the heat transfer efficiency, affects the boiler's performance; it can easily cause metal materials to burn due to localized overheating, even leading to pipe explosion accidents; it also accelerates galvanic corrosion, causing pipeline scale corrosion, and speeds up the damage to the heat-absorbing surface. Once scale forms, it should be promptly removed using either mechanical or chemical methods.

Heat Exchanger and Refrigeration Equipment Cleaning - Choose GreenChem for Assurance
