Connector steel grating panels type

There are four types of interlocking steel grating panels: They can be categorized as pressed steel grating, heavy-duty steel grating, integral steel grating, and sunshade curtain steel grating, etc., based on different insertion methods and angles.

1. Pressed Steel Grating: After cutting grooves in the carrying flat steel, the crossbar flat steel is pressed and locked into shape. The processing height for producing standard steel grating is 100mm. The length of the steel grating is usually less than 2000mm.

2. Heavy-duty interlocking steel grating is a type of steel grating product made by interlocking high flange steel with crossbar flange steel, and then tightly formed under 1200 tons of pressure. It is suitable for high span and high load-bearing applications.

3. Integrated Steel Grating Panels - The load-bearing flat steel and cross-bar flat steel of the integrated steel grating panels have the same height and slot depth, which is half of the load-bearing flat steel's depth. The height of the steel grating panel does not exceed 100mm. The length of the steel grating panel is usually less than 2000mm.

4. Sunshade Type Interlocking Steel Grating: The sunshade type interlocking steel grating features load-bearing flat bars with 30° or 45° slits, and the slot bars are locked into place through slotting. We can deliver gratings with different spacing and specifications as per requirement, available in materials such as carbon steel, stainless steel, aluminum, etc. The height of the grating is less than 100mm.
