Plug-inSteel Grating PlatesType

Plug-inSteel Grating PlateTypes can be divided into four categories: pressed based on different insertion methods and angles.Steel Grating PlatesOverloadSteel Grating PlatesIntegratedSteel Grating PlatesSunshade curtain styleSteel Grating PlatesPlease wait.

1.Compression type plug-inSteel Grating Plates:After cutting slots in the steel flats being carried,Bar steel press lock forming. Production of standard typeSteel Grating PlatesThe processing height is:100mm。Steel Grating PlatesLength is typically less than2000mm。

2.Heavy-duty plug-inSteel Grating PlatesIt is a high flat steel and crossbar flat steel interlocking structure.1200A pressure-formed material under tons of pressureSteel Grating PlatesProduct. It is suitable for high load-bearing spans.

3.Integrated plug-inSteel Grating PlateIntegrated connectorSteel Grating PlatesThe bearing flat steel and crossbar flat steel have the same height and slot depth as the bearing flat steel.1/2。Steel Grating PlatesHeight not exceeding100mm。Steel Grating PlatesLength is typically less than2000mm。

4.Sunshade type connectorSteel Grating Plates:Sunshade type connectorSteel Grating PlatesFlat steel carrying capacity30°Or45°Chute,Slotting, flattening, and locking molding of channel steel. We can deliver grating panels with various spacings and specifications according to different needs, which can be made from materials such as ordinary carbon steel, stainless steel, aluminum, etc. The height of the grating panels is less than100mm。
