Product Introduction
RRHX Electric Elastic Seat Sluice Valves (with Handle), RVHX Electric Non-Handle Elastic Seat Sluice Valves, Z945X Electric Non-Handle Soft Seal Sluice Valves, Z941X Electric Soft Seal Sluice Valves (with Handle), and other electric sluice valves are compatible with various electric actuators for remote and automatic control. They feature sensitivity, reliability, and easy installation, and are widely used on fluid pipelines in water supply, sewage, construction, petroleum, chemical, food, pharmaceutical, light industry, textile, power ships, metallurgy, and energy systems as regulating and cutoff devices.
Product Features
Key components material
| Serial Number | Part Name | Material |
|---|---|---|
| 1 | Valve body | Grey Cast Iron, Ductile Iron, Cast Steel |
| 2 | Gate valve | QT Ductile Iron with EPDM or Nitrile Rubber Coating |
| 3 | Valve Stem | 45 steel, 40Cr stainless steel |
| 4 | Valve Cover | Gray Cast Iron, Ductile Cast Iron, Cast Steel |
| 5 | Bracket | Grey Cast Iron, Ductile Cast Iron, Cast Steel |
| 6 | Electric Head | DZW series multi-revolution electric valve actuators |
Primary connection dimensions
| DN | 50 | 65 | 80 | 100 | 125 | 150 | 200 | 250 | 300 | 350 | 400 | 450 | 500 | 600 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| L | 178 | 190 | 203 | 229 | 254 | 267 | 292 | 330 | 356 | 381 | 406 | 432 | 457 | 508 |
| H (Full Open) | 732 | 773 | 820 | 870 | 915 | 1003 | 1110 | 1263 | 1630 | 1550 | 1610 | 1900 | 1938 | 2120 |
| Category | Details |
|---|---|
| Model | Z945X - 10/16Q/C/P etc. |
| Connection Type | Flanges, welding, etc. |
| Material | Cast steel, stainless steel, carbon steel, etc. |
| Nominal Bore Size | DN15~DN1800 mm |
| Applicable Medium | Water, steam, oil products, various highly corrosive chemical media, weak acid and alkaline media, ammonia gas, nitrogen gas, oxygen, hydrogen gas, liquefied gas, air, coal gas, dust-containing gas |
| Sealing Type | Rigid-sealed |
| Standard | National Standard, American Standard, German Standard, etc. |
| Appearance | Medium to large sizes |
| Flow Direction | Bidirectional |
| Drive Method | Electric, manual, etc. |
| Parts and accessories | Bolts, washers, etc. |
| Usage | Control the opening, closing, and adjustment of pipeline media |
| Pressure Environment | PN0.6~1.6MPa |
| Operating Temperature | -25~+80℃ |
| Type | Direct shipment |
| Control Type | Switch-type, Adjust-type, Explosion-proof, Integrated |
| Type of Protection | Outdoor, Standard Explosion-Proof, Mine-Used Explosion-Proof, etc. |
| Ingress Protection (IP) rating | IP65 |
| Power Voltage | Standard AC380V 50Hz |
| Lead Time | Payment in 3 days for shipment |
| Control and feedback signals | 4-20mA DC analog signal or switch signal |
Product Packaging & After-Sales Service
Our company packages this series of products uniformly in wooden boxes, which is convenient for transportation and provides excellent protection for the products. In terms of quality and service assurance, we solemnly promise:
If you have any questions about the product, please call our 24-hour service hotline at 15821856533, or log in to our website. Our company will arrange an engineer to answer your questions as soon as possible. We are always committed to serving you wholeheartedly and providing excellent service.
Logistics Distribution
Multiple logistics and delivery options are available, including SF Express, YTO Express, EveryDay Express, and national intermodal transport. You can freely select based on your needs. Delivery destinations include major cities, transit points, and major ports domestically and internationally.
DeclarationAll text, data, and images in this article are for reference only. For specific product performance parameters, structural dimensions, prices, and other detailed information, please contact the relevant department personnel of our company. 24-hour service hotline: 15821856533.
