Japan Magnescale Caliper Sensor DK805SAFLR
Measurement Range: 5mm, 12mm, 30mm
Resolution: 0.1 µm, 0.5 µm
Accuracy: 1µm p-p to 1.7µm p-p (varies by model)
Response Speed: 80m/min at 0.1µm resolution, 250m/min at 0.5µm resolution
Bearing Structure: Utilizes high durability ball spline bearings, enhancing sliding performance
Slide Count: Over 320 million or more (testing continues as of January 2021)
Protection Rating: Supports IP67 (Straight or Right-angle type, with air tube installed)
Built-in origin
Output Signal: A/B phase (pulsed), home position (differential line driver signal with output voltage difference)
We also offer flanged types that can be securely fastened.
| Main Specifications | ||
|---|---|---|
※1 The items marked with () are type B ※2 Excludes the internal box and connector parts ※3 Right-angled and using φ4mm tube ※4 Excludes cable parts and insertion boxes ※5 The shapes and dimensions of some parts are different from the previous DK800 series models. Changes to the recorded content will not be notified separately. | ||
| Model | High-resolution model | Universal Resolution Type |
| DK805SAR，DK805SALR，DK805SAFR，DK805SAFLR DK805SBR，DK805SBLR，DK805SBFR，DK805SBFLR | DK805SAR5，DK805SALR5，DK805SAFR5，DK805SAFLR5 DK805SBR5，DK805SBLR5，DK805SBFR5，DK805SBFLR5 | |
| Measurement Range | 5mm | |
| Resolution | 0.1µm | 0.5µm |
| Accuracy (at 20℃) | 1µm p-p | 1.5µm p-p |
| Measurement Force (at 20℃) | Up: 0.35 ± 0.25 N | |
| Horizontal: 0.40 ± 0.25 N | ||
| Down: 0.45 ± 0.25 N | ||
| Operating Temperature Range | 0 ~ +50℃ (No condensation) | |
| Storage Temperature Range | -20 ~ +60°C (90%RH or less) | |
| Response Speed ※1 | 80m/min (42m/min) | 250m/min (100m/min) |
| Spindle Drive Method | Spring Compression (All Models) Air-driven through vacuum aspiration (DK805S*LR*) | |
| Original Response Speed | With the same response speed as mentioned above | |
| Origin Position | Spindle movement of 1mm ±0.5mm | |
| Ingress Protection (IP) Rating ※2 | Linear: IP67; Right-angle: IP64 (IP67 ※3) | |
| Vibration-resistant | 100m/s2 (20 ～ 2,000 Hz) | |
| Impact-resistant | 1000m/s2 (11ms) | |
| Power Voltage | DC 5V ±5% | |
| Power Consumption | 1W | |
| Output | A/B/Origin Differential Line Driver Signal (Compliant with EIA-422) | |
| Quality: ※4 | Approx. 30g | |
| Probe | Spherical super-hard alloy ball, installed with M2.5 screws | Steel ball surface with M2.5 installation screws |
| Output Cable Length | 2.5m | |
| Accessories | 1 instruction manual, +2 PM4×5 screws, set screw, wrench, lock washer 1 each installation pin (only for DK8**S*F**), 1 each soft tube elbow (only for DK8**S*L**), 1 each wrench | |
