Magnetic detection method
Good environmental resistance, oil-resistant, dust-proof, shock and vibration-resistant
Resolution: 10 µm
Up to 2 meters in length
The ruler has a small size and a simple structure, making it easy to install.
From wood and stone processing machines to large metal processing machines
Main Application: Wood and Stone Processing Machines
High-Speed Response: 300m/minWith PL20CAssembled (when combined)
| Main Specifications | ||
|---|---|---|
Accuracy is the value when combined with the probe cable PL20C/PL25, or with the probe cable PL81/82, which includes an internal junction box. Changes to the recorded content will not be announced separately. | ||
| Model | SL110 | |
| Measuring Range (L) | 200，300，400，500，600，700，800，1000，1200，1500，1600，1700，1800，2000 mm | |
| Full Length | Measurement Range: +103mm | |
| Accuracy (at 20℃)*1 | (50+10L/1000) µm Range: Measurement (mm) | |
| Permitted for parallelism installation | Grating face direction | Under 0.8mm / Full Length |
| Ruler side direction | 1.0mm or less / full length | |
| Coefficient of Linear Expansion | (10.4±1)×10-6/℃ | |
| Operating Temperature Range | -5 ～ +45°C | |
| Temperature Storage Range | -10 ～ +50°C | |
| Applicable Read Head Cable | PL20C / PL25 | |
| Cable with compatible plug-in box (sold separately) | PL81 / PL82 / PL25 / PL20C (for connecting monitors) | |
