Magnetic detection method
Good environmental resistance, oil resistance, dustproof, shock and vibration resistance
Resolution: 10 µm
Up to 2 meters in length
The ruler has a small size and a simple structure, making it easy to install.
From wood and stone processing machines to metalworking machinery, a large range of heavy machinery
Main Application: Wood and Stone Processing Machines
High-speed Response: 300m/minWith PL20CAssembled (when applicable)
| Main Specifications | ||
|---|---|---|
Accuracy value when combined with the PL20C/PL25 reading head cable, and the PL81/82 reading head cable with an internal connector box. Changes to the recorded content will be made without prior notice. | ||
| Model | SL110 | |
| Measurement Range (L) | 200，300，400，500，600，700，800，1000，1200，1500，1600，1700，1800，2000 mm | |
| Full Length | Measurement Range: +103mm | |
| Accuracy (at 20°C)*1 | (50+10L/1000) µm Range: Measurement (mm) | |
| Permission to install parallelism | Grating face orientation | 0.8mm and under / full length |
| Ruler side direction | 1.0mm and under / full length | |
| Coefficient of linear expansion | (10.4±1)×10-6/℃ | |
| Operating Temperature Range | -5 ～ +45°C | |
| Storage Temperature Range | -10 ～ +50°C | |
| Applicable sensor cable | PL20C / PL25 | |
| Head cable with applicable insert box (sold separately) | PL81 / PL82 / PL25 / PL20C (for connecting monitors) | |
