Mitsubishi Peak Holding Digital Indicator 543-300B-10

Mitutoyo Sensitive Peak Retaining Digital Indicator 543-300B-10

543 Series

Peak Hold ABSOLUTE Digital Indicator ID-C112AX2

● Peak detection function with GO / ± NG judgment for peaks. *1

● Featuring 5 buttons, status icons, and key-assisted displays, various functions are easy to operate.

● Equipped with a large LCD screen and analog bar display.

● Utilizing Sankyo's developed Absolute (ABSOLUTE) encoder, no need to reset to zero after power off and then on again *2, eliminating overspeed errors and enhancing measurement reliability.

● By utilizing the parameter setting suite (options) and software, various functions and parameters can be set from the PC.

Equipped with a data output port for measurement, capable of connecting to Statistical Process Control systems and measurement data network systems.

■ Features

Peak Detection Function (High/Low)

●Function for detecting the amplitude of fluctuations (difference between high and low values during the motion) Note: Peak detection capability

Sample Rate: 50 times per second

② Capture Speed: 50 µm/sec

Zeroing Function (INC Measurement System Origin Setting)

● Preset Function (ABS Measurement System Origin Setting)

Count Direction Conversion Function

● Tolerance Judgment Function (ABS three sets, INC can be stored)

Resolution Switch Function

●Simple Calculation Function f(x) = Ax

● Simulated Divider Value Switch Function

● Function lock feature

● Hold Display Value Feature (when not connected to external devices)

Data Output Function

● External PC Settings Input Function

● Display Section Rotating Function (330°)

Low Voltage Warning Display

● Error Warning Display
