Mitutoyo's 543-720B Digital Indicator Caliper

Mitutoyo Sinebar Indicator 543-720B Threading Micrometer

543 Series

ABSOLUTE Digital Indicator ID-CNX (Supports Bi-directional Communication)

● Supports bidirectional serial communication, featuring the new-generation ID-C series with various new functions. Compatible with optional communication cables and software.

Batch zeroing and various editing settings for indicator tables via PC operation greatly enhance work efficiency.

●Digital and analog displays provide a clear perception of the approach to tolerance and the amount of insertion, etc., with fine variations.

●By setting a calibration appointment date, alerts can be displayed to assist with proper gauge management.

●Utilizing the SICK-developed Absolute Encoder (ABSOLUTE) sensor, there's no need for home position recovery* every time power is turned on, and it also eliminates overspeed errors, offering excellent reliability.

● Equipped with a measurement data output port, capable of connecting to Statistical Process Control Systems and Measurement Data Network Systems.

■ Features

Peak Hold Function (High, Low)

● Function for measuring the amplitude of fluctuation (difference between the maximum and minimum values during the action)

Zeroing Function (INC Measurement System Origin Setting)

● Pre-set Function (ABS Measurement System Origin Setting)

Count Direction Conversion Function

● Tolerance Judgment Function

Resolution Switching Function

(Only for models with a resolution of 0.0005 mm)

● Simple calculation function f(x) = Ax

● Function Lock Feature

Calibration Time Warning Feature

● Auto OFF Feature

Data Output Function

● Hold Display Value Function (when the connection line is not connected)

● Display Section Rotation Function (330°)

Low Voltage Warning Display

● Error Warning Display
