RLA94 Linear Electric Cylinder

The linear electric cylinder integrates AC servo motor, servo driver, high-precision ball screw, modular design, and other technologies, featuring a compact structure, low inertia, fast response, low noise, and long lifespan. The servo motor is directly connected to the transmission screw of the cylinder, reducing the inertia and clearance of intermediate links, enhancing control and precision. The servo motor is integrated with the cylinder for easy installation and convenient use. The main components of the cylinder are all made with internationally renowned brand products, ensuring stable performance, low failure rate, and high reliability.

Product Details Description

Section 1: Servo Electric Cylinder Working Principle
An electric cylinder is a modular, integrated design product that converts the rotational motion of a servo motor into linear motion through the mechanical motion of a screw and screw nut assembly. By utilizing the closed-loop control characteristics of the servo motor, precise control of thrust, speed, and position can be easily achieved; combined with mechanical motion technology and programmed control technology, it realizes programmed and numerical control. It is a revolutionary new product for achieving high-precision linear motion control.

Section II: Electric Cylinder Types
Direct-Connected Servo Electric Cylinder
The direct-acting servo electric cylinder integrates AC servo motor, servo driver, high-precision ball screw, modular design, and other technologies, featuring a compact structure, low inertia, fast response, low noise, and long lifespan. The servo motor is directly connected to the cylinder's transmission screw, reducing the inertia and clearance of intermediate links, enhancing control and precision. The servo motor is integrated with the cylinder for easy installation and convenient use. The main components of the cylinder are all made with internationally renowned brand products, ensuring stable performance, low failure rate, and high reliability.
2. Return-to-zero electric cylinder
Retractable electric cylinders are suitable for installations with limited space due to their short overall length. Moreover, the imported synchronous belts used in this solution offer high strength, small gaps, and long lifespan, ensuring the entire cylinder has excellent controllability and precision. The servo motor pairs well with the cylinder, featuring easy installation, simple setup, and convenient operation.

Section 3: Electric Cylinder Models

4. Overview of Electric Cylinder Features

1. Precise path location and controllability
2. Modular assembly applications, saving mechanical design space
3. Suitable for high-speed, high-frequency operation
4. Precision and easy installation
5. Multi-point positioning and multi-segment control
6. Optional installation accessories and methods available for diverse selection
7. Available with a variety of complete sets of motors and controllers.
8. A variety of products are available for selection.
9. Simple design, low maintenance costs, and easy to handle.

V. Instructions and Precautions for Electric Cylinder Use
1. The electric cylinder is a precision electromechanical integrated transmission device. Please carefully read the precautions and the instruction manuals for the motor, driver, and other components before use.
2. This product features an internal strong magnet, equipped with a magnetic induction switch and a stroke limit warning sign externally. Please fine-tune the required stroke within the warning sign area.
3. Our company uses a fully sealed device, filled with high-quality lubricant, requiring no regular maintenance from the customer; for certain high-frequency and high-speed models, we have a customized design with a lubricant injection port.
4. When adjusting the servo electric cylinder, it should be operated at low speed initially. Increase the speed only after all aspects are functioning normally to prevent damage to the electric cylinder.

Section 6: Applicability Scope
Multi-degree-of-freedom simulation and emulation, multi-degree-of-freedom motion entertainment, precision machining, robots, mechanical lifting platforms, automotive presses, automotive manufacturing equipment, mechanical automation production lines, petrochemicals, material handling, injection molding machines, mold control, valve control, precision machine tools, food industry, and more.

Section 7: After-Sales Instructions and Recommendations
1. This product comes with a 18-month warranty from the date of factory shipment, under normal usage conditions (excluding intentional damage).
2. Damage caused by human factors or other abnormal usage is not covered under the warranty.
3. Unauthorized disassembly of the electric cylinder without the manufacturer's permission is not covered under warranty, including any self-disassembly or modification.
