Technical Parameters Structure

1. This product has been tested by the National Security Technology Evaluation Center and meets the national confidentiality standard BMB19-2006 for "Electronics and Information Technology Equipment."

Technical Requirements and Testing Methods for Magnetic Leakage Emission Shielding Cabinet > C-Level Requirements, the installation and use of this product should comply with

Comply with the product's stated operating environment, and use fiber optic cables for communication in actual use.

2, Model: NYHL-C Type

3. Appearance: Aesthetically pleasing (Surface paint color: Black)

4. Housing: A fully enclosed box made of cold-rolled steel plate, 1.5mm thick, which is焊接 with galvanized and painted for corrosion resistance.

Process;

5, Shielded Door: Doors made of precision-manufactured and processed shielding springs and cold-rolled steel plate welding

Assembled shielded door (with mechanical lock)

6. Equipment Bracket: Adjustable in up, down, front, and back positions; comes with 20 matching bolts.

7. Server Rack Shelves Placement: Standard 2-meter server cabinet is equipped with three shelves.

Standard cabinets 1.4 meters and below are equipped with two shelves.

8. Ventilation wave guide windows: Honeycomb design, one set each at top and bottom, 300*300mm.

9. Swivel Wheels: Durable and sturdy, allowing smooth multi-directional and multi-angle movement.

10, Axial fan with more than 18,000 hours of trouble-free operation, single exhaust flow rate of 1.4 m3/min. 4 pieces.

11. Power filter with wide suppression bandwidth and high insertion loss; AC 220V x 16A, 1 set

12, Overload-protected electrical socket, 10A, 6-way 3-slot, 1 set

13, Φ8.1*100mm Copper Waveguide (Shielded Category 6 Ethernet Cable) (Standard Configuration: 5 Pieces)

14, Fiber Optic Waveguide Ф12*140 Galvanized Fiber Optic Conduit (Standard Configuration: 5 Pieces)

15, Ground bolt 1 piece

16, Swivel wheel each with a load capacity of not less than 150K x 4
