GXL series paper box compression testing machine

The Compression Strength Tester for Corrugated Boxes is a professional machine used for testing the compressive strength of boxes, suitable for the compression tests of corrugated boxes, honeycomb boxes, and other packaging containers. It is also applicable for the compression tests of containers such as plastic drums (edible oil, mineral water), paper drums, paper boxes, paper cans, and bulk containers (IBC drums).



Application Range:

Cardboard boxes, beer boxes, paper tubes, paper cups, color boxes, milk boxes, etc.; food and beverage packaging for instant noodles, cosmetic packaging, beer packaging, grain and oil packaging, etc.

Product Features:

Determine compressive strength, stacking strength, and set strength

Product Features

Precise mechanical design features two precision ball screws and precision guide rods, ensuring high parallelism of the upper and lower pressure plates during testing and stable high-speed transmission of the instrument; The mainboard employs a completely new design, with a 32-bit ARM processor for the CPU, enhancing the instrument's processing speed and allowing for more accurate and rapid data computation.

Utilizing a 5-inch color touch screen with Chinese display and touch buttons for simple and intuitive operation, it features real-time display of pressure deformation curve and other information such as time; the instrument boasts powerful data display, analysis, and management capabilities, along with data saving functions; capable of storing up to 10,000 sets of test data; equipped with high-precision pressure sensors and unique sampling algorithm software, significantly enhancing the instrument's measurement accuracy; uses thermosensitive printer cores, eliminating the need for ink and ribbons, operates quietly, and prints rapidly; comes with a standard RS232 interface for communication with computer software (sold separately); available for customized non-standard design according to customer requirements.

Manufacturing.

Key Technical Parameters

Power Voltage: AC (220±10%) V, 50Hz

2. Working Environment: Temperature (10～35)°C, Relative Humidity ≤ 85%

3. Measuring Range: (0～5) kN / (0～10) kN / (0～20) kN / (0～30) kN / (0～50) kN (optional)

4. Resolution: 1N

5. Display Accuracy: ±1%

6. Plate Area: 600×600mm / 600×800 / 800×800mm / 1000×1000mm / Custom Sizes Available

7. Work Schedule: 600mm/800mm/1000mm/Custom Sizes Available

8. Pressure Increase Rate: 10 mm/min (1-99) mm/min (adjustable)

9. Parallelism of upper and lower plates: ≤1mm (600×600mm) / ≤1.5mm (800×800mm) / ≤2mm (1000×1000mm)

10. Return Speed: (1~120) mm/min, adjustable as desired

11. Printing: Built-in thermal printer

12. Communication Interface: RS232

Standard Configuration

Pressure Test Machine Main Unit, Printing Paper, Power Cord

Optional accessories

RS232 Interface and Microcomputer Software (sold separately)

Execution Standard:

GB/T 4857.4，GB/T 4857.3，QB/T 1048 ，ISO 12408，ISO 2234
