The GX-MF500全自动正压加压试水密封仪 is an all-in-one automated waterproof testing machine for electronic products or other items (such as smartphones, watches, lenses, electric toothbrushes, and electronic valuables, etc.), offering superior performance, intuitive testing, and non-destructive to products. The design of the instrument complies with national and international standards, making it an essential professional testing equipment for manufacturing enterprises, research institutions, and testing organizations.


Testing Method:


Positive pressure is filled into the sealed drum, the air pressure enters the product under test, then the product is submerged in water, and the gas in the sealed drum is released. At this point, the air pressure inside the product under test is higher than that in the sealed drum. If the product under test bubbles, it indicates that gas was introduced into the product during pressurization, suggesting poor sealing performance. If no bubbles appear, it means no gas was introduced into the product during pressurization, indicating no leakage and good sealing performance.


Simulated IEC 60529 Edition 2.1:2001-02 IPX2-IPX8 samples are fully submerged in water according to the specified normal operating conditions, and the waterproof performance of the product is directly observed. Fully automatic model, system parameters:


One-touch start, automatic test completion. Devotedly monitoring for any air leakage in the product, it is currently the most cost-effective choice among products! Test pressure range: 0-1000 kPa, display resolution: 1 kPa. Pressure gauge with automatic compensation, test setup time with automatic prompt. Timing control range: 0-9999 seconds, adjustable, display resolution: 1 second. Test setup: adjustable. Power supply: 220V/50Hz. Exhaust pipe: Φ8mm high-quality imported Taiwan TPU pipe. Power safety protection: Equipped with power safety protection measures. Sealing performance standard: Simulated ISO, GB/T 15171, ASTM D3078, IEC 60529 Edition 2.1:2001-02. Vacuum chamber effective size: Φ300mm × 350mm (H) (standard). Net weight: 42kg. Configuration: Main unit, sealing drum, sealing ring, sealing lid, wire, rubber cup, instruction manual, certificate of conformity, warranty card. Each item included.
