High Precision 4-Station CNC Flange Drilling Machine: The Bossman 4-Station CNC Drilling and Milling Machine is primarily used for the processing of annular flange parts. It can also efficiently perform drilling, threading, countersinking, and milling operations on workpieces such as half shafts, plates, rings, etc., within the effective thickness range. It is capable of drilling through holes and blind holes in both solid material and composite material components. The machine's processing is digitally controlled, making operation very convenient. It can achieve automation, high precision, a variety of products, and large-scale production.

Equipment Structure: This equipment consists mainly of a bed working table, four sets of hydraulic four-jaw self-centering chuck, mobile gantry, moving saddle, drilling power head, and automatic lubrication unit.

High-precision 4-axis CNC flange drilling machine

Equipment Usage:

The Boschman four-axis CNC drilling and milling machine is primarily used for processing ring flange workpieces, and can also efficiently perform drilling/tapping/reaming/milling operations on workpieces with thicknesses within the effective range, such as halfshafts, disks, rings, etc. It can achieve through-drilling and blind holes on both solid material and composite material parts. The machine tool processing process is digitally controlled, offering great ease of operation. It can achieve automation, high precision, multi-product, and large-scale production.

Equipment Structure:

This equipment is primarily composed of a bed working table, four hydraulic four-jaw self-centering chuck sets, a movable gantry, a movable saddle, a drilling power head, an automatic lubrication unit and protective devices, a circulating cooling unit, a digital control system, and an electrical system, etc. It features rolling linear guide supports and guides, precision screw drives, and the machine tool boasts high positioning accuracy and repeat positioning accuracy.

Bossman 4-station flange automatic blanking CNC gantry drill for automotive drive shaft/gear shaft CNC drilling

The Bossman four-spindle high-speed flange drilling machine is primarily used for efficient drilling processing of workpieces with external diameters up to 500mm, including flange-type, half-shaft, disc, ring, and other types of workpieces with thicknesses within the effective range.

The four-station high-speed drilling machine features 4 hydraulic chuck jaws, capable of using internal coolant tools (U-drills) for continuous non-stop cycle processing of workpieces. The operator only needs to load and unload materials, achieving 3-5 times the processing efficiency of standard radial arm drills and bench drills. The machine tool's processing process is digitally controlled, offering easy operation and achieving machine substitution. It can drill through holes and blind holes in both single-element material parts and composite materials. It is capable of achieving automated, high-precision, multi-type, and large-volume production.

Applicable Industries: Flange industry, half-shaft types, ring components, etc., for workpieces with an outer diameter of approximately 500mm.
