| Stationary Transducer Main Technical Parameters | |||||||||||
| Model | ZHB1 | ZHB3 | ZHB6 | ZHB10 | ZHB20 | ZHB30 | ZHB50 | ZHB100 | ZHB150 | ZHB200 | |
| Rated Load Capacity (T) | 0.1 | 0.3 | 0.6 | 1 | 2 | 3 | 5 | 10 | 15 | 20 | |
| Rotation Speed (rpm) | 0.2-2 | 0.1-1 | 0.05-0.5 | 0.05-0.5 | 0.05-0.5 | 0.05-0.5 | 0.05-0.5 | 0.02-0.2 | 0.02-0.2 | 0.028-0.28 | |
| Revolution Speed (rpm) | Manual | ≈0.3 | ≈0.3 | ≈0.3 | ≈0.3 | ≈0.3 | ≈0.2 | ≈0.2 | ≈0.2 | ≈0.2 | |
| Workbench Diameter (mm) | Φ300 | Φ600 | Φ800 | Φ1000 | Φ1200 | Φ1400 | Φ1500 | Φ2000 | Φ2000 | Φ2500 | |
| Maximum eccentricity (mm) | 100 | 100 | 100 | 100 | 150 | 150 | 200 | 200 | 200 | 200 | |
| Workbench Tilt Angle (°) | 0-90 | 0-120 | 0-115 | 0-135 | 0-135 | 0-135 | 0-135 | 0-135 | 0-135 | 0-135 | |
| Rotation Motor Power (kW) | 0.09 | 0.18 | 0.37 | 0.37 | 0.75 | 1.5 | 2.2 | 3 | 3 | 4 | |
| Reversing Motor Power (kW) | Manual | 0.25 | 0.37 | 0.75 | 1.5 | 2.2 | 3 | 4 | 5.5 | 7.5 | |
| Maximum Rotational Diameter at 90° (mm) | ≤450 | ≤850 | ≤1250 | ≤1700 | ≤2000 | ≤2400 | ≤2800 | ≤3200 | ≤3300 | ≤3500 | |
| Dimensions (mm) | Long L | 460 | 1000 | 1000 | 1440 | 1650 | 2120 | 2400 | 2850 | 3400 | 3810 |
| Wide W | 382 | 800 | 820 | 1060 | 1200 | 1400 | 1500 | 2000 | 2250 | 2500 | |
| High H | 400 | 650 | 880 | 1057 | 1220 | 1465 | 1660 | 1939 | 2000 | 2098 | |
