Product Introduction
RQ-UV Series Pipe/Flow-through Ultraviolet Sterilizers
Principle of Ultraviolet Sterilization
1. Directly eliminate bacteria and algae in water with ultraviolet light, without the need for heating or chemical products.
2. During the sterilization process, no by-products are produced, thereby avoiding secondary contamination.
3. This series of equipment achieves a sterilization rate of 99% - 99.9%.
4. Features include broad-spectrum antibacterial effectiveness, no secondary pollution, safe and reliable operation, and low operating costs.
Application Fields
1. Water Purification and Disinfection: Potable water, secondary water supply, drinking water, pure water, aquaculture, food and beverage processing water, pharmaceutical water, and high-purity water for electronics.
2. Wastewater Disinfection: Municipal wastewater, reclaimed wastewater, hospital wastewater, slaughterhouse effluent, oilfield reinjection water
3. Recirculating Water Disinfection: Swimming Pool Water, Landscape Water, Industrial Recirculating Cooling Water
4. Shellfish purification, agricultural irrigation water disinfection, algae removal from large water bodies
5. Field operations, aircraft, naval vessels, submarine water disinfection
Structure Introduction
1. Utilizing high-quality UV tubes with a lifespan of over 12,000 hours
2. Utilizing high-quality optical quartz glass tubes, ensuring excellent light transmission and mechanical strength.
3. Utilizing hygienic grade 304, 316L stainless steel tubes with thickness ≥ 2mm
4. National standard stainless steel flanges, national standard pure copper wire
Highly customizable
1. Customizable water in/out port diameter
2. Import/Export locations customizable, such as side entry and side exit, or opposite side entry and exit
3. Control cabinets are customizable, with options for an integrated sterilizer-control cabinet or a separate design.
4. Flange center distance is customizable; import/export distance can be adjusted according to customer requirements.
5. Optional automatic cleaning device for the convenience of eliminating manual lamp tube cleaning
