Product Features

1. System soft start, no surge current, strong voltage adaptability.

2. Utilizes a special variable frequency power supply with adjustable frequency and voltage, ensuring the equipment maintains optimal operating conditions at all times.

3. Special dry-type transformers, stable operation, and strong adaptability to working environments.

4. High-frequency ionization generates ozone with high efficiency; liquid oxygen is used as the gas source without the need for nitrogen addition.

5. Electrode 316L stainless steel, imported German glass discharge medium, lifespan over 20 years.

6. Siemens PLC automatic control with automatic protection against overheating, overcurrent, overvoltage, and water shortage.

Performance Parameters

1. Ozone Concentration: 80-200 mg/L (Oxygen Source)

2. Inlet Pressure: 0.1～0.7 MPa

3. Venting Pressure: 0.02～0.1 MPa

4. Inlet Dew Point: -60℃

5. Cooling Water Volume: 1.5 T/kg•O3•h (Oxygen Source)

6. Cooling water temperature rise: 4-6℃

7. Ozone Output Adjustment: 10% - 100%

8. Power Consumption: 8 kWh/kg O3 (oxygen source)

9. Power: 380V•50Hz

10. Operating room environmental temperature: 0°C to 40°C
