Special Separation System - Juice Clarification, Filtration, and Concentration Separation Equipment - Quankun - Customization Supported

Membrane separation is a method that utilizes the differential selectivity of the membrane to the various components in a mixture, driven by an external energy or chemical potential difference, to separate, grade, purify, and concentrate binary or multi-component gas or liquid mixtures. Membrane pores are at the nanoscale, suitable for separating solutes with molecular weights of 100 to 1000 and molecular sizes of approximately 1nm, which is referred to as nanofiltration (NF). The transmembrane pressure required for NF membrane separation is generally 0.5 to 2.0 MPa, which is lower by 0.5 to 3 MPa than the pressure needed for reverse osmosis membranes to achieve the same osmotic energy.MPa. Based on operating pressure and separation limits, NF can be qualitatively positioned between reverse osmosis and ultrafiltration, and is sometimes referred to as "low-pressure reverse osmosis" or "loose reverse osmosis."

Process Flow:

Membrane concentration equipment is typically categorized by different membrane elements, such as microfiltration, ultrafiltration, nanofiltration, and reverse osmosis experimental equipment, crossflow experimental equipment, tangential flow filtration experimental equipment, and multi-stage membrane experimental equipment. The processes all rely on the lifting power of the pump after the raw liquid tank, in conjunction with the pore size of the membrane elements, to achieve separation, purification, and concentration.

Process Features:

Easy installation and use, convenient maintenance, simple yet practical technology, and aesthetically pleasing appearance.

Membrane concentration and separation equipment is easy to operate, stable in performance, made of stainless steel, and resistant to acid and alkali corrosion.

The equipment is compact in structure, small in size, and does not occupy too much space.

Small circulation volume, excellent separation and purification effect.

Equipment is easy to clean, and the membrane core can be used in a cyclic manner for a long time.

The equipment can operate at pressures up to 40 kg, with a wide range of applications.

Special Separation System - Juice Clarification and Filtration Concentration Separation Equipment - Quankun - Customization Supported

Please consult the sales engineers at Jiangsu Quankun Environmental Protection Technology Co., Ltd. They can provide imported membrane elements and membranes in various materials and molecular weight cut-offs, tailored to your specific requirements. They also offer laboratory-grade pure water and ultra-pure water equipment, as well as membrane separation equipment for reverse osmosis, nanofiltration, and ultrafiltration, in both Chinese industrial scale and production capacity.
