• Semi-enclosed structure

• Travel: 100-1500mm

• Maximum Speed: 5 m/s

• Continuous Thrust Range: 295.7-1140.7N

Peak Thrust Range: 721.8-2808.4N

• Guide Rail Specifications: 20#-2 pcs

Product Features

Wear-free and maintenance-free

Contactless transmission method adopted

Minimize mechanical friction losses to the maximum extent

Less frequent malfunctions, maintenance-free

Operational safety and reliability, long lifespan

Endless Journey------

Achieve design for any journey

Add multiple stators of different lengths to meet customer requirements.

Strong adaptability to speed------

Achieve high-speed and low-speed operation

High rigidity------

The motor and load of the linear module have no transmission gap.

During loaded movement, it boasts high dynamic rigidity.

High dynamic response performance------

Highly accelerated large motor

Typically, you can get 2-5G of acceleration.

Small electric motors typically achieve acceleration exceeding 10G.

Product Specifications

Naming Rules:

Technical Specifications:

Product Dimensions:
