Yinteng Tower-type Constant Temperature and Humidity Air Conditioner

Specification: YT-9HW

Brand: YingTeng

Cooling Capacity: 9 kW

Heating Output KW: 4.5

Airflow: 2000 m³/h

Static Wind Pressure Outside the Machine: 50-200 Pa

Engine noise dB: 55

Humidity and Temperature Control Range: 16-30℃ ±2℃; 40-70% ±5%

Input Power: AC 380V 50Hz

Input Total Power KW: 9

Compressor Type: Panasonic Twin Rotor

Compressor Power: 3.0 kW

Heater Type: Electric Heating Tube

Humidifier Type: Electrode Humidifier

Humidification Rate/Power: 2.2/Kg/3/Kw

Copper tube union pipe diameter: liquid tube 12, gas tube 19

Dimensions (H*W*D) for cabinet unit: 1900*950*550 mm

Outdoor unit quantity: 1

Outdoor Unit Dimensions (Height*Width*Depth) MM: 1230*980*460

Manufacturer: Henan Tongteng Explosion Proof Electrical Equipment Co., Ltd.

Note: The above technical specifications are for reference only, and the physical unit shall prevail.

Yinteng Constant Temperature and Humidity Air Conditioning Product Features

Attractive appearance, easy maintenance: The unit features a patented cold-bridge prevention design, with a simple yet elegant frame structure, a dignified and generous look, seamlessly blending with the indoor environment; the controller's status display, parameter modification, and fault inquiries all use Chinese prompt menus for easy and convenient operation.

Reliable performance, stable quality: Equipped with self-control components for refrigeration systems from European and American brands like DANFOSS and ALCOSPORLAN, with stable quality controllers from manufacturers such as Schneider and OMRON, ensuring reliable performance. The unit is configured with multiple protection devices including high and low-pressure, exhaust temperature, fan, and compressor overload relays, guaranteeing safe operation.

Quiet operation, ultra-low noise: Equipped with the latest fully enclosed low-noise compressor, minimal vibration and noise; the compressor is isolated from the air handling system with an external compressor or dual-stage vibration reduction device, ensuring noise does not interfere or overlap; in addition, the inner side of the wall panels is lined with thermal insulation and sound-absorbing foam; thus, the noise level is extremely low.

Energy-saving and efficient, intelligent control: Utilizing high-purity internal threaded copper tubes and hydrophilic finned aluminum baffles, the heat transfer coefficient is 30% higher than that of ordinary evaporators; Equipped with top-brand PLC control, featuring built-in PID analog quantity adjustment for strong adaptability and high control accuracy, achieving ±1°C temperature and ±3% relative humidity; The PLC controller is equipped with multiple automatic control functions, including fault diagnosis, energy control, and operating modes, ensuring the unit's efficient operation.
