Medium Temperature
Scope

-60℃～+220℃

Control System

CPU collects PID for independent operation ,Fuzzy Self-Constructive Tree AlgorithmPLC Controller

Temperature-controlled mold
Style selection

Material temperature control and equipment export temperature control mode are freely selectable.

Temperature Difference Control

The temperature difference between the equipment's export temperature and the reaction material temperature can be controlled and set.

Programmer Editor

Programmable for 10 routines, each routine is programmable99Section steps

Communication Protocol

RS-485 Interface

External temperature接入
Degree of feedback

PT100

Temperature Feedback

Thermal Conductive Medium Equipment - Inlet Temperature, Outlet Temperature, Reactor Material Temperature - Three Temperature Points

Thermal Conductive Medium
Temperature Control Accuracy

±0.5℃

±1℃

Reactive Material
Temperature Control Accuracy

±1℃

±1.5℃

Heating Power
kW

2.5

3.5

5.5

7.5

10

15

25

38

60

95

130

200

Manufacture
Cold
Quantity
kW
AT
℃

220

2.5

3.5

5.5

7.5

10

15

25

38

60

95

130

200

100

2.5

3.5

5.5

7.5

10

15

25

38

60

95

130

200

20

2.5

3.5

5.5

7.5

10

15

25

38

60

95

130

200

-20

2

3

4.8

6

8.2

12

25

38

56

80

90

150

-40

0.95

1.45

2.3

3.1

4.8

7.8

18

23

31

45

56

93

-55

0.25

0.5

0.75

0.9

1.5

2.8

6

8

11

16

20

32

Flow pressure
max L/min
bar

20

35

50

50

110

110

150

200

250

400

400

600

1

1

1

1

2.5

2.5

2.5

2.5

2.5

2.5

2.5

2.5

Compressor

France Taikang

Duelling, Italy

Expansion valve

Danfoss/Emerson thermal expansion valve

Evaporator

Gao Li Plate Heat Exchanger

Operation Panel

7-inch color touch screen, temperature curve display and recording

Safety Protection

Features self-diagnosis function; overload protection; high and low pressure switches, overload relays, thermal protection devices, and various other safety functions.

Sealed circulation
System

The entire system is fully enclosed, free of oil mist at high temperatures and does not absorb moisture from the air at low temperatures.System is runningMaintain constant pressureAuto-fill thermal conductive medium。

Refrigerant

R-404A

Interface dimensions

DN20

DN20

DN20

DN25

DN25

DN25

DN32

DN40

DN40

DN50

DN65

DN65

外形尺寸
(Breeze)mm

455*855
*1305

555*1005
*1755

555*1005
*1755

705*1005
*1755

805*1205
*1855

/

/

/

/

/

/

/

外形尺寸
(Water)mm

455*855
*1305

455*855
*1305

555*1005
*1755

555*1005
*1755

705*1005
*1755

805*1205
*1855

1005*1505
*1855

2055*1455
*2055

2055*1455
*2055

2455*1455
*2255

3005*1605
*2255

4005*1605
*2255

Weight: kg

225

245

320

360

400

400

1000

1370

1600

1970

2700

3300

Power Supply
380V
50HZ

5.5kW

8kW

10.5kW

14.5kW

18.5kW

26.5kW

40.5kW

61.5kW

95.5kW

145.5kW

200.5kW

315.5kW
