Refrigeration and Heating Temperature Control System ATC-4N25 -40℃
Type#
ATC-
425ATC-
435ATC-
455ATC-
475ATC-
4N10ATC-
4N15ATC-
4N25ATC-
4N38WATC-
4N60WATC-
4N95WATC-
4N130WATC-
4N200WMedium Temperature
Scope-40℃～+220℃
Control System
CPU collects PID for independent operation ,Fuzzy Self-Constructive Tree AlgorithmPLC Controller
Temperature Control Mode
ChooseMaterial temperature control and equipment export temperature control mode are freely selectable.
Temperature Difference Control
The temperature difference between the equipment's export temperature and the reaction material temperature can be controlled and set.
Programmer Editing
Can program 10 routines, each routine can be programmed99Paragraph steps
Communication Protocol
RS-485 Interface
External temperature connection
FeedbackPT100
Temperature Feedback
Thermal Conductive Medium Equipment Inlet Temperature, Outlet Temperature, Reactor Material Temperature – Three Temperature Points
Thermal Conducting Medium
Temperature Control Accuracy±0.5℃
±1℃
Reactive Material
Temperature Control Accuracy±1℃
±1.5℃
Heating Power
kW2.5
3.5
5.5
7.5
10
15
25
38
60
95
130
200
Manufacture
Cold
Quantity
kW
AT
℃2.0
2.5
3.5
5.5
7.5
10
15
25
38
60
95
130
200
100
2.5
3.5
5.5
7.5
10
15
25
38
60
95
130
200
20
2.5
3.5
5.5
7.5
10
15
25
38
60
95
130
200
0
1.8
3
5
7
10
15
25
38
60
95
130
200
-20
0.85
1.5
2.9
4.2
6
11
16
26
34
50
70
120
Pump Flow Rate & Pressure
max
L/min
bar20
35
50
50
110
110
150
200
250
400
400
600
1
1
1
1
1
2.5
2.5
2.5
2.5
2.5
2.5
2.5
Compressor
French Taikang, Emerson Copeland, Italian DulexBosch piston
Expansion valve
Danfoss/Emerson thermal expansion valves
Evaporator
Gao Li Plate Heat Exchanger
Operation Panel
7-inch color touch screen, temperature curve display and recording
Safety Protection
Features self-diagnosis function; overload protection for the refrigerator; safety features including high-pressure pressure switch, overload relay, thermal protection device, etc.
Sealed Recirculation
SystemThe entire system is fully enclosed, free of oil mist at high temperatures, and does not absorb moisture from the air at low temperatures. The system operates smoothly.Maintain constant pressureAutomatically replenishes the thermal conductive medium.
Refrigerant
R-404A/R507C
Interface Size
DN15
DN15
DN20
DN20
DN25
DN25
DN32
DN40
DN50
DN50
DN65
DN65
Dimensions
(Wind)mm455*855
*1305455*855
*1305555*105
*1755555*105
*1755705*105
*1755805*1205
*18551005*1505
*1855/
/
/
/
/
Dimensions
(Water)mm455*855
*1305455*855
*1305455*855
*1305455*855
*1305555*1005
*1755555*1005
*1755805*1205
*18551005*1505
*18552055*1455
*20552055*1455
*20552455*1455
*20553005*1605
*2255Weight: kg
150
200
215
280
340
410
640
840
1120
1370
1700
2260
Power Supply
380V
50hzAC220V
5kW7kW
9.5kW
12kW
16.5kW
24kW
36.5kW
55.5kW
90kW
135.5kW
180.5kW
280.5kW
The temperature control accuracy is typically ±1°C, and it can be connected to an external sensor.
2. Equipped with a PLC computer module, capable of connecting to a computer for remote control. It offers multi-point continuous temperature control, segmented temperature control, and constant temperature control, allowing a single computer to manage multiple high and low temperature devices.
3. Equipped with a USB port, featuring data download capabilities.
4. High-Temperature Limitation, Prevents Equipment from Derailing [If the temperature exceeds the equipment's set point, the equipment will automatically shut off to prevent damage to the equipment due to excessive heat.]
5. Power Protection [① Phase Loss of Power Supply ② Incorrect Phase Sequence ③ Overvoltage or Undervoltage]
6. Overheat Protection for Compressors (The compressor will stop working when it reaches the maximum bearing capacity.)
7. Water-cooled with water flow and low water pressure protection.
8. Sensor Protection
9. All compressors are imported (from France and Denmark).
Refrigeration and Heating Temperature Control System ATC-4N25 -40℃
