Product Specifications
Model: YTBC-5000
Brand: YingTeng
Cooling Capacity: 5000W
Internal temperature range: 25℃~38℃
External cabinet temperature range: -5℃ to 45℃
System Pressure Resistance: 26bar
Power: 220V/50Hz
Operating Current: 11A
Input Power: 2200W
Cabinet air circulation volume: 900 m³/h
Cabinet external air volume: 2300 m³/h
Internal Protection Rating: IP54
External Protection Rating: IP34
Noise: 70 dB(A)
Weight: 80 kg
Dimensions (width x height x depth): 475*1300*370mm
Description:
Test conditions are: dry bulb humidity inside the electrical cabinet at 35°C, wet bulb temperature at 26°C, and dry bulb temperature outside the electrical cabinet at 35°C.
2. The above product specifications are for the standard model. For larger cooling capacity or customized products, please call our company for details.
Product Features
Equipped with temperature control and dehumidification functions to ensure ideal temperature and humidity requirements within the electrical control cabinet.
Utilizing high-efficiency scroll-type rotor compressors, offering high reliability, low energy consumption, and stable quality.
The air inside the cabinet does not exchange heat with the ambient air, ensuring the internal air of the electrical cabinet remains clean.
Choose high-volume, high-static-pressure centrifugal fans for better air circulation and heat exchange efficiency.
Proper air intake and exhaust design to prevent short-circuiting of air circulation inside the cabinet.
The full-touch screen controller can be equipped with alarm and dehumidification functions, and can monitor the operating status of the air conditioner in real-time.
Compact, lightweight, and extremely easy to install, use, and maintain.
Application Scope
Now widely used in machine tools, data processing, communication, finance, metallurgy, petrochemical, construction materials, and automotive industries, some large-scale domestic data processing centers and CNC machining centers have also been extensively utilized. The exceptional efficiency and superior performance of the electrical cabinet air conditioners are gradually gaining recognition and adoption from an increasing number of high-end clients both domestically and internationally.
Selection Examples
The control cabinet surface area is 8㎡ (A=8㎡), and the environmental temperature is 35°C (T0=35°C). The total heat generated inside the cabinet is 150W. To maintain an internal cabinet temperature of 28°C, the following calculation method for selecting the electrical cabinet air conditioner is recommended:
△T=T0-Ti=35-28=7°C
Qr=5.5xAx△T=5.5x8x7=308W
Qt=1.2x（Qr+Qi）=1.2x（150+308）=458W
Choose the air conditioner model YTBC-600.
