| Serial Number | Project | Name | Parameters |
| 1 | Structural form | Number of shaft ends: | 1 shaft |
| Workstation: | 1 station | ||
| Worktop Size: | 1590mm*1030mm | ||
| Workbench Load: | 700kg | ||
| 2 | Spindle Mechanism | Control Method: | Variable Frequency Motor + Synchronous Belt |
| Spindle Motor: | 5.5KW | ||
| Machining hole diameter range: | Φ100-Φ500mm (optional sizes outside this range available) | ||
| Transmission range: | 50-600 rpm (Variable speed) | ||
| 3 | Stroke mechanism | Control Method: | Servo Motor + Ball Screw |
| Stroke Speed MAX: | 28m/min | ||
| Stroke Length MAX: | 600mm | ||
| 4 | Feeding mechanism | Control Method: | Servo Motor + Ball Screw |
| Feeding Type: | Constant Feed Rate | ||
| Feed Resolution: | 0.1um | ||
| 5 | Other | Equipment Weight: | Approximately 5.5 tons |
| Equipment Dimensions (Length x Width x Height): | 1650x1600x2500 | ||
| Noise Standard: | Under standard factory conditions, the continuous load peak is less than 75 decibels. | ||
| Power Supply: | Three-phase AC: 380V 50Hz | ||
| Environmental Conditions: | Temperature -10~+45°C Temperature < 72% |
