| Serial Number | Project | Name | Parameters |
| 1 | Structural form | Number of shaft ends: | 1 shaft |
| Workstation: | 1 workstation | ||
| Desk Top Size: | 1250mm*900mm | ||
| Workbench Load: | 500kg | ||
| 2 | Spindle Mechanism | Control Method: | Variable Frequency Motor + Synchronous Belt |
| Spindle Motor: | 2.2KW | ||
| Machining Hole Diameter Range: | Φ2-Φ60mm (optional in sizes outside this range) | ||
| Gear ratio range: | 50-3,000 rpm (Continuous variable speed) | ||
| 3 | Cylinder mechanism | Control Method: | Servo Motor + Ball Screw |
| Stroke Speed MAX: | 40m/min | ||
| Stroke Length MAX: | 350mm | ||
| 4 | Feeding Mechanism | Control Method: | Servo Motor + Ball Screw |
| Feeding Type: | Constant Feed Rate | ||
| Feeding Resolution: | 0.1um | ||
| 5 | Other | Equipment Weight: | Approximately 2.5 tons |
| Equipment dimensions (Length x Width x Height): | 1500x1500x2350 | ||
| Noise Standard: | In standard factory settings, continuous loading peak noise level is less than 75 decibels. | ||
| Power Supply: | Three-phase AC: 380V 50Hz | ||
| Environmental Conditions: | Temperature -10~+45°C Temperature < 72% |
